Danfoss VLT AutomationDrive FC 301 Instruction Manual

8.1.2 Line Power Supply 380–500 V
Type designation PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical shaft output (hp [kW])
0.5
[0.37]
0.75
[0.55]
1.0
[0.75]
1.5
[1.1]
2
[1.5]
19.47
[2.2]
4
[3.0]
5
[4.0]
7.5
[5.5]
10
[7.5]
Enclosure protection rating IP20 (FC 301 only) A1 A1 A1 A1 A1 - - - - -
Enclosure protection rating IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure protection rating IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current high overload 160% for 1 min
Shaft output (hp [kW])
0.5
[0.37]
0.75
[0.55]
1.0
[0.75]
1.5
[1.1]
2
[1.5]
3
[2.2]
4
[3]
5
[4]
7.5
[5.5]
10
[7.5]
Continuous (380–440 V) [A] 1.3 1.8 2.4 3.0 4.1 5.6 7.2 10 13 16
Intermittent (380–440 V) [A] 2.1 2.9 3.8 4.8 6.6 9.0 11.5 16 20.8 25.6
Continuous (441–500 V) [A] 1.2 1.6 2.1 2.7 3.4 4.8 6.3 8.2 11 14.5
Intermittent (441–500 V) [A] 1.9 2.6 3.4 4.3 5.4 7.7 10.1 13.1 17.6 23.2
Continuous kVA (400 V) [kVA] 0.9 1.3 1.7 2.1 2.8 3.9 5.0 6.9 9.0 11
Continuous kVA (460 V) [kVA] 0.9 1.3 1.7 2.4 2.7 3.8 5.0 6.5 8.8 11.6
Maximum input current
Continuous (380–440 V) [A] 1.2 1.6 2.2 2.7 3.7 5.0 6.5 9.0 11.7 14.4
Intermittent (380–440 V) [A] 1.9 2.6 3.5 4.3 5.9 8.0 10.4 14.4 18.7 23
Continuous (441–500 V) [A] 1.0 1.4 1.9 2.7 3.1 4.3 5.7 7.4 9.9 13
Intermittent (441–500 V) [A] 1.6 2.2 3.0 4.3 5.0 6.9 9.1 11.8 15.8 20.8
Additional specifications
IP20, IP21 maximum cable cross-section
2)
for
line power, motor, brake and load sharing
[mm
2
] ([AWG])
4,4,4 (12,12,12)
(min. 0.2(24))
IP55, IP66 maximum cable cross-section
2)
for
line power, motor, brake and load sharing
[mm
2
] ([AWG])
4,4,4 (12,12,12)
Maximum cable cross-section
2)
for disconnect
[mm
2
] ([AWG])
6,4,4 (10,12,12)
Estimated power loss at rated maximum load
(hp [W])
3)
0.047
[35]
0.056
[42]
0.062
[46]
0.078
[58]
0.083
[62]
0.118
[88]
0.156
[116]
0.166
[124]
0.251
[187]
0.342
[255]
Efficiency
4)
0.93 0.95 0.96 0.96 0.97 0.97 0.97 0.97 0.97 0.97
Table 8.4 Line Power Supply 380–500 V (FC 302), 380–480 V (FC 301), PK37-P7K5
Specifications Instruction Manual
MG33AP22 Danfoss A/S © Rev. 09/2014 All rights reserved. 55
8 8

Danfoss VLT AutomationDrive FC 301 Specifications
