Type designation P11K P15K P18K P22K
High/Normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output (hp [kW]) 15 [11] 20 [15] 20 [15] 25 [18.5] 25 [18.5] 30 [22.0] 30 [22.0] 40 [30.0]
Enclosure protection rating IP20 B3 B3 B4 B4
Enclosure protection rating IP21 B1 B1 B2 B2
Enclosure protection rating IP55, IP66 B1 B1 B2 B2
Output current
Continuous (380–440 V) [A] 24 32 32 37.5 37.5 44 44 61
Intermittent (60 s overload) (380–440 V) [A] 38.4 35.2 51.2 41.3 60 48.4 70.4 67.1
Continuous (441–500 V) [A] 21 27 27 34 34 40 40 52
Intermittent (60 s overload)
(441–500 V) [A]
33.6 29.7 43.2 37.4 54.4 44 64 57.2
Continuous kVA (400 V) [kVA] 16.6 22.2 22.2 26 26 30.5 30.5 42.3
Continuous kVA (460 V) [kVA] 21.5 27.1 31.9 41.4
Maximum input current
Continuous (380–440 V) [A] 22 29 29 34 34 40 40 55
Intermittent (60 s overload)
(380–440 V) [A]
35.2 31.9 46.4 37.4 54.4 44 64 60.5
Continuous (441–500 V) [A] 19 25 25 31 31 36 36 47
Intermittent (60 s overload)
(441–500 V) [A]
30.4 27.5 40 34.1 49.6 39.6 57.6 51.7
Additional specifications
IP21, IP55, IP66 maximum cable cross-section
2)
for line power, brake and load sharing
[mm
2
] ([AWG])
16, 10, 16 (6, 8, 6) 16, 10, 16 (6, 8, 6) 35, -, - (2, -, -) 35, -, - (2, -, -)
IP21, IP55, IP66 maximum cable cross-section
2)
for motor [mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, 25, 25 (2, 4, 4) 35, 25, 25 (2, 4, 4)
IP20 maximum cable cross-section
2)
for line
power, brake, motor and load sharing
[mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, -, - (2, -, -) 35, -, - (2, -, -)
Maximum cable cross-section
2)
for disconnect
[mm
2
] ([AWG])
16, 10, 10 (6, 8, 8)
Estimated power loss at rated maximum load
(hp [W])
3)
0.390 [291] 0.526 [392]
0.508
[379]
0.624
[465]
0.595
[444]
0.704
[525]
0.734
[547]
0.991
[739]
Efficiency
4)
0.98 0.98 0.98 0.98
Table 8.5 Line Power Supply 380–500 V (FC 302), 380–480 V (FC 301), P11K-P22K
Specifications Instruction Manual
56 Danfoss A/S © Rev. 09/2014 All rights reserved. MG33AP22
