Danfoss VLT AutomationDrive FC 301 Instruction Manual

Type designation P30K P37K P45K P55K P75K
High/Normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output (hp [kW]) 40 [30] 50 [37] 50 [37] 60 [45] 60 [45] 75 [55] 75 [55] 100 [75] 100 [75] 125 [90]
Enclosure protection rating IP21 C1 C1 C1 C2 C2
Enclosure protection rating IP20 B4 C3 C3 C4 C4
Enclosure protection rating IP55,
IP66
C1 C1 C1 C2 C2
Output current
Continuous (380–440 V) [A] 61 73 73 90 90 106 106 147 147 177
Intermittent (60 s overload)
(380–440 V) [A]
91.5 80.3 110 99 135 117 159 162 221 195
Continuous (441–500 V) [A] 52 65 65 80 80 105 105 130 130 160
Intermittent (60 s overload)
(441–500 V) [A]
78 71.5 97.5 88 120 116 158 143 195 176
Continuous kVA (400 V) [kVA] 42.3 50.6 50.6 62.4 62.4 73.4 73.4 102 102 123
Continuous kVA (460 V) [kVA] 51.8 63.7 83.7 104 128
Maximum input current
Continuous (380–440 V) [A] 55 66 66 82 82 96 96 133 133 161
Intermittent (60 s overload)
(380–440 V) [A]
82.5 72.6 99 90.2 123 106 144 146 200 177
Continuous (441–500 V) [A] 47 59 59 73 73 95 95 118 118 145
Intermittent (60 s overload)
(441–500 V) [A]
70.5 64.9 88.5 80.3 110 105 143 130 177 160
Additional specifications
IP20 maximum cable cross-section
for line power and motor
[mm
2
] ([AWG])
35 (2) 50 (1) 50 (1) 150 (300 MCM) 150 (300 MCM)
IP20 maximum cable cross-section
for brake and load sharing
[mm
2
] ([AWG])
35 (2) 50 (1) 50 (1) 95 (4/0) 95 (4/0)
IP21, IP55, IP66 maximum cable
cross-section for line power and
motor [mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 150 (300 MCM) 150 (300 MCM)
IP21, IP55, IP66 maximum cable
cross-section for brake and load
sharing [mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 95 (3/0) 95 (3/0)
Maximum cable cross-section
2)
for
line power disconnect
[mm
2
] ([AWG])
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM,
300 MCM, 4/0)
Estimated power loss
at rated maximum load (hp [W])
3)
1.033
[570]
0.936
[698]
0.935
[697]
1.131
[843]
1.195
[891]
1.452
[1083]
1.371
[1022]
1.856
[1384]
1.652
[1232]
1.977
[1474]
Efficiency
4)
0.98 0.98 0.98 0.98 0.99
Table 8.6 Line Power Supply 380–500 V (FC 302), 380–480 V (FC 301), P30K-P75K
Specifications
Instruction Manual
MG33AP22 Danfoss A/S © Rev. 09/2014 All rights reserved. 57
8 8
