8 Specifications
8.1 Electrical Data
8.1.1 Line Power Supply 200–240 V
Type designation PK25 PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P3K7
Typical shaft output (hp [kW])
0.34
[0.25]
0.5
[0.37]
0.75
[0.55]
1.0
[0.75]
1.5
[1.1]
2
[1.5]
3
[2.2]
4
[3.0]
5
[3.7]
Enclosure protection rating IP20 (FC 301 only) A1 A1 A1 A1 A1 A1 - - -
Enclosure protection rating IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure protection rating IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
Continuous (200–240 V) [A] 1.8 2.4 3.5 4.6 6.6 7.5 10.6 12.5 16.7
Intermittent (200–240 V) [A] 2.9 3.8 5.6 7.4 10.6 12.0 17.0 20.0 26.7
Continuous kVA (208 V) [kVA] 0.65 0.86 1.26 1.66 2.38 2.70 3.82 4.50 6.00
Maximum input current
Continuous (200–240 V) [A] 1.6 2.2 3.2 4.1 5.9 6.8 9.5 11.3 15.0
Intermittent (200–240 V) [A] 2.6 3.5 5.1 6.6 9.4 10.9 15.2 18.1 24.0
Additional specifications
Maximum cable cross-section
2)
for line power,
motor, brake and load sharing [mm
2
] ([AWG])
4,4,4 (12,12,12)
(min. 0.2 (24))
Maximum cable cross-section
2)
for disconnect
[mm
2
] ([AWG])
6,4,4 (10,12,12)
Estimated power loss at rated maximum load
(hp [W])
3)
0.028
[21]
0.039
[29]
0.056
[42]
0.072
[54]
0.085
[63]
0.110
[82]
0.156
[116]
0.208
[155]
0.248
[185]
Efficiency
4)
0.94 0.94 0.95 0.95 0.96 0.96 0.96 0.96 0.96
Table 8.1 Line Power Supply 200–240 V, PK25-P3K7
