Danfoss VLT AutomationDrive FC 301 Instruction Manual

525–600 V
Recommended maximum fuse
Power
(hp
[kW])
Buss-
mann
Type RK1
Buss-
mann
Type J
Buss-
mann
Type T
Buss-
mann
Type CC
Buss-
mann
Type CC
Buss-
mann
Type CC
SIBA
Type RK1
Littelfuse
Type RK1
Ferraz-
Shawmut
Type RK1
Ferraz-
Shawmut
J
1–1.5
[0.75–
1.1]
KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5 5017906-005 KLS-R-005 A6K-5-R HSJ-6
2–3
[1.5–
2.2]
KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10 5017906-010 KLS-R-010 A6K-10-R HSJ-10
4 [3] KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15 5017906-016 KLS-R-015 A6K-15-R HSJ-15
5 [4] KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20 5017906-020 KLS-R-020 A6K-20-R HSJ-20
7.5 [5.5] KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25 5017906-025 KLS-R-025 A6K-25-R HSJ-25
10 [7.5] KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30 5017906-030 KLS-R-030 A6K-30-R HSJ-30
15 [11] KTS-R-35 JKS-35 JJS-35 - - - 5014006-040 KLS-R-035 A6K-35-R HSJ-35
20 [15] KTS-R-45 JKS-45 JJS-45 - - - 5014006-050 KLS-R-045 A6K-45-R HSJ-45
24 [18] KTS-R-50 JKS-50 JJS-50 - - - 5014006-050 KLS-R-050 A6K-50-R HSJ-50
30 [22] KTS-R-60 JKS-60 JJS-60 - - - 5014006-063 KLS-R-060 A6K-60-R HSJ-60
40 [30] KTS-R-80 JKS-80 JJS-80 - - - 5014006-080 KLS-R-075 A6K-80-R HSJ-80
50 [37] KTS-R-100 JKS-100 JJS-100 - - - 5014006-100 KLS-R-100 A6K-100-R HSJ-100
60 [45] KTS-R-125 JKS-125 JJS-125 - - - 2028220-125 KLS-R-125 A6K-125-R HSJ-125
75 [55] KTS-R-150 JKS-150 JJS-150 - - - 2028220-150 KLS-R-150 A6K-150-R HSJ-150
100
[75]
KTS-R-175 JKS-175 JJS-175 - - - 2028220-200 KLS-R-175 A6K-175-R HSJ-175
Table 8.21 525–600 V, Enclosure Types A, B and C
525–690 V
Recommended maximum fuse
Power
(hp [kW])
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
1.5 [1.1] KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
2–3
[1.5–2.2]
KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
4 [3] KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
5 [4] KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
7.5 [5.5] KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
10 [7.5] KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
15 [11] KTS-R-35 JKS-35 JJS-35 - - -
20 [15] KTS-R-45 JKS-45 JJS-45 - - -
24 [18] KTS-R-50 JKS-50 JJS-50 - - -
30 [22] KTS-R-60 JKS-60 JJS-60 - - -
40 [30] KTS-R-80 JKS-80 JJS-80 - - -
50 [37] KTS-R-100 JKS-100 JJS-100 - - -
60 [45] KTS-R-125 JKS-125 JJS-125 - - -
75 [55] KTS-R-150 JKS-150 JJS-150 - - -
100 [75] KTS-R-175 JKS-175 JJS-175 - - -
Table 8.22 525–690 V, Enclosure Types A, B and C
Specifications
Instruction Manual
MG33AP22 Danfoss A/S © Rev. 09/2014 All rights reserved. 75
8 8

Danfoss VLT AutomationDrive FC 301 Specifications
