Danfoss VLT AutomationDrive FC 301 Instruction Manual

Type designation P37K P45K P55K P75K
High/Normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output (hp [kW]) 50 [37] 60 [45] 60 [45] 75 [55] 75 [55] 100 [75] 100 [75] 125 [90]
Enclosure protection rating IP20 C3 C3 C3 C4 C4
Enclosure protection rating IP21, IP55, IP66 C1 C1 C1 C2 C2
Output current
Continuous (525–550 V) [A] 54 65 65 87 87 105 105 137
Intermittent (525–550 V) [A] 81 72 98 96 131 116 158 151
Continuous (551–600 V) [A] 52 62 62 83 83 100 100 131
Intermittent (551–600 V) [A] 78 68 93 91 125 110 150 144
Continuous kVA (550 V) [kVA] 51.4 61.9 61.9 82.9 82.9 100.0 100.0 130.5
Continuous kVA (575 V) [kVA] 51.8 61.7 61.7 82.7 82.7 99.6 99.6 130.5
Maximum input current
Continuous at 550 V [A] 49 59 59 78.9 78.9 95.3 95.3 124.3
Intermittent at 550 V [A] 74 65 89 87 118 105 143 137
Continuous at 575 V [A] 47 56 56 75 75 91 91 119
Intermittent at 575 V [A] 70 62 85 83 113 100 137 131
Additional specifications
IP20 maximum cable cross-section for line power and
motor [mm
2
] ([AWG])
50 (1) 150 (300 MCM)
IP20 maximum cable cross-section for brake and load
sharing [mm
2
] ([AWG])
50 (1) 95 (4/0)
IP21, IP55, IP66 maximum cable cross-section for line
power and motor [mm
2
] ([AWG])
50 (1) 150 (300 MCM)
IP21, IP55, IP66 maximum cable cross-section for brake
and load sharing [mm
2
] ([AWG])
50 (1) 95 (4/0)
Maximum cable cross-section
2)
for line power
disconnect [mm
2
] ([AWG])
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM,
300 MCM, 4/0)
Estimated power loss at rated maximum load (hp
[W])
3)
0.992
[740]
1.207
[900]
1.207
[900]
1.475
[1100]
1.475
[1100]
2.012
[1500]
2.012
[1500]
2.414
[1800]
Efficiency
4)
0.98 0.98 0.98 0.98
Table 8.9 Line Power Supply 525–600 V (FC 302 only), P37K-P75K
Specifications Instruction Manual
60 Danfoss A/S © Rev. 09/2014 All rights reserved. MG33AP22
88
