Danfoss VLT AutomationDrive FC 361 Programming Guide

5.2.17 18-** Data Readouts 2
Param
eter
numb
er
Parameter description Default value 4 set-up Change
during
operation
Conversion
index
Type
18-5* Active Alarms/Warnings
18-55 Active Alarm Numbers 0 N/A All set-ups TRUE 0 Uint16
18-56 Active Warning Numbers 0 N/A All set-ups TRUE 0 Uint16
18-9* PID Readouts
18-90 Process PID Error 0 % All set-ups FALSE -1 Int16
18-91 Process PID Output 0 % All set-ups FALSE -1 Int16
18-92 Process PID Clamped Output 0 % All set-ups FALSE -1 Int16
18-93 Process PID Gain Scaled Output 0 % All set-ups FALSE -1 Int16
5.2.18 21-** Ext. Closed Loop
Param
eter
numb
er
Parameter description Default value 4 set-up Change
during
operation
Conversion
index
Type
21-1* Ext. CL 1 Ref./Fb.
21-10 Ext. 1 Ref./Feedback Unit [1] % All set-ups TRUE – Uint8
21-11 Ext. 1 Minimum Reference 0 ExtPID1Unit All set-ups TRUE – Int32
21-12 Ext. 1 Maximum Reference 100 ExtPID1Unit All set-ups TRUE – Int32
21-13 Ext. 1 Reference Source [0] No function All set-ups TRUE – Uint8
21-14 Ext. 1 Feedback Source [0] No function All set-ups TRUE – Uint8
21-15 Ext. 1 Setpoint 0 ExtPID1Unit All set-ups TRUE – Int32
21-17 Ext. 1 Reference [Unit] 0 ExtPID1Unit All set-ups TRUE – Int32
21-18 Ext. 1 Feedback [Unit] 0 ExtPID1Unit All set-ups TRUE – Int32
21-19 Ext. 1 Output [%] 0 % All set-ups TRUE – Int32
21-2* Ext. CL 1 PID
21-20 Ext. 1 Normal/Inverse Control [0] Normal All set-ups TRUE – Uint8
21-21 Ext. 1 Proportional Gain 0.01 N/A All set-ups TRUE -2 Uint16
21-22 Ext. 1 Integral Time 10000 s All set-ups TRUE 0 Uint32
21-23 Ext. 1 Dierentation Time 0 s All set-ups TRUE 0 Uint16
21-24 Ext. 1 Dif. Gain Limit 5 N/A All set-ups TRUE – Uint16
Parameter Lists VLT® AutomationDrive FC 361
176 Danfoss A/S © 03/2019 All rights reserved. MG06J202
