VLT
®
AutomationDrive EtherNet/IP
MG.90.Jx.02 ver. 5
th
September 2007 – VLT is a registered Danfoss trademark 27
Bit 12, Drive OK/stopped, auto start:
Bit 12 = ‘0’ means that there is no temporary
over temperature on the inverter.
Bit 12 = ‘1’ means that the inverter has
stopped because of over temperature, but that
the unit has not tripped and will resume
operation once the over temperature stops.
Bit 13, Voltage OK/limit exceeded
:
Bit 13 = ‘0’ means that there are no voltage
warnings.
Bit 13 = ‘1’ means that the DC voltage in the
frequency converter’s intermediate circuit is
too low or too high.
Bit 14, Torque OK/limit exceeded
:
Bit 14 = ‘0’ means that the motor current is
lower than the torque limit selected in par.
4-18 Current limit.
Bit 14 = ‘1’ means that the torque limit in par.
4-18 Current limit has been exceeded.
Bit 15, Timer OK/limit exceeded
:
Bit 15 = ‘0’ means that the timers for motor
thermal protection and VLT thermal protection,
respectively, have not exceeded 100%.
Bit 15 = ‘1’ means that one of the timers has
exceeded 100%.
