Danfoss VLT AutomationDrive Manual

VLT
®
AutomationDrive EtherNet/IP
- P a r a m e t e r s –
MG.90.Jx.02 ver. 5
th
September 2007 – VLT is a registered Danfoss trademark 43
Parameter List
PNU Parameter Name Default value Range Conv. Index Data Type Array
8-0x Communication and options
8-01 Control Site Dig. and ctrl. word [0] [0 - 2] - Unsigned 8 -
8-02 Control Word Source Option A [3] [0 - 4] - Unsigned 8 -
8-03 Control Word Timeout Time 1.0 s 0.1 - 18000 -1 Unsigned 32 -
8-04 Control Word Timeout
Function
Off [0] [0 - 10] - Unsigned 8 -
8-05 End-of-timeout Function Hold set-up [0] [0 - 1] - Unsigned 8 -
8-06 Reset Control Word Timeout Do not reset [0] [0 - 1] - Unsigned 8 -
8-07 Diagnosis Trigger Disable [0] [0 - 3] - Unsigned 8 -
8-10 Control Word Profile FC profile [0] [0 - 5] - Unsigned 8 -
8-13 Configurable Status Word Profile default [1] [0 – 85] - Unsigned 8 [12-15]
8-5x Digital/Bus
8-50 Coasting Select Logic OR [3] [0 - 3] - Unsigned 8 -
8-51 Quick Stop Select Logic OR [3] [0 - 3] - Unsigned 8 -
8-52 DC Brake Select Logic OR [3] [0 - 3] - Unsigned 8 -
8-53 Start Select Logic OR [3] [0 - 3] - Unsigned 8 -
8-54 Reversing Select Logic OR [3] [0 - 3] - Unsigned 8 -
8-55 Set-up Select Logic OR [3] [0 - 3] - Unsigned 8 -
8-56 Preset Reference Select Logic OR [3] [0 - 3] - Unsigned 8 -
12-0x IP settings
12-00 IP Address Assignment 0.0.0.0 0 - 255 - Unsigned 8 -
12-01 IP Address 0.0.0.0 0 – 255 - Oct. string 4 -
12-02 Subnet Mask 0.0.0.0 0 – 255 - Oct. string 4 -
12-03 Default Gateway 0.0.0.0 0 - 255 - Oct. string 4 -
12-04 DHCP Server 0.0.0.0 0 - 255 - Oct. string 4 -
12-05 Lease Expires 00:00:00:00 - - Time diff. w/date -
12-06 Name Servers 0.0.0.0 0 - 255 - Oct. string 4 -
12-07 Domain Name - max. 19 ch. - Visible string 48 -
12-08 Host Name - max. 19 ch. - Visible string 48 -
12-09 Physical Address 00:1B:08:00:00:00 - - Visible string 17 -
12-1x Ethernet Link Parameters
12-10 Link Status No Link [0] [0 - 1] - Unsigned 8 [0-1]
12-11 Link Duration 00:00:00:00 - - Time diff. w/date [0-1]
12-12 Auto Negotiation On [1] [0 - 1] - Unsigned 8 [0-1]
12-13 Link Speed None [0] [0 - 2] - Unsigned 8 [0-1]
12-14 Link Duplex Full Duplex [1] [0 - 1] - Unsigned 8 [0-1]
12-2x Process Data
12-20 Control Instance None 20 - 103 - Unsigned 8 -
12-21 Process Data Config Write - - - Unsigned 16 [0-9]
12-22 Process Data Config Read - - - Unsigned 16 [0-9]
12-28 Store Data Values Off [0] [0 – 1] - Unsigned 8 -
12-29 Store Always Off [0] [0 - 1] - Unsigned 8 -
12-3x EtherNet/IP
12-30 Warning Parameter 0000 hex 0000–FFFF - Unsigned 16 -
12-31 Net Control Off [0] [0 - 1] - Unsigned 8 -
12-32 Net Reference Off [0] [0 - 1] - Unsigned 8 -
12-33 CIP Revision 00 0 – 99 - Unsigned 16 [0-1]
12-34 CIP Product Code 0 9999 - Unsigned 16 [0-1]
12-37 COS Inhibit Timer 0 0 - 65535 0 Unsigned 16 -
12-38 COS Filters 0000 0000-FFFF - Unsigned 16 [0-9]
12-8x Other Ethernet Services
12-80 FTP Server Disable [0] [0 – 1] - Unsigned 8 -
12-81 HTTP Server Disable [0] [0 – 1] - Unsigned 8 -
12-82 SMTP Service Disable [0] [0 – 1] - Unsigned 8 -
12-89 Transp. Socket Channel Port Disable [0] [0 – 1] - Unsigned 8 -
12-9x Advanced Ethernet Settings
12-90 Cable Diagnostics Disable [0] [0 - 1] - Unsigned 8 -
12-91 Auto Cross-Over Enable [0] [0 - 1] - Unsigned 8 -
12-92 IGMP Snooping Enable [0] [0 - 1] - Unsigned 8 -
12-93 Cable Error Length 0 0 - 200 0 Unsigned 16 [0-1]
12-94 Broadcast Storm Protection 0 Off – 20% - Unsigned 16 [0-1]
12-95 Broadcast Storm Filter Enable [1] [0 - 1] - Unsigned 8 [0-1]
12-98 Interface Counters 0 0 - 65535 - Unsigned 16 [0-10]
12-99 Media Counters 0 0 - 65535 - Unsigned 16 [0-11]

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
