Danfoss VLT AutomationDrive Manual

VLT
®
AutomationDrive EtherNet/IP
MG.90.Jx.02 ver. 5
th
September 2007 – VLT is a registered Danfoss trademark 8
LED Behaviour
The option LED’s operates according to ODVA specifications.
MS: Module Status
State LED Description
No power Off
The device is un-powered
Device
operational
Green: █████████████
Solid green
The device is operational
Standby
Green: ▂█▂█▂█▂█▂█▂█▂
Flashing green
The device needs commissioning
Minor fault
Red: ▂█▂█▂█▂█▂█▂█▂█
Flashing red
The device has detected a recoverable
fault
Major fault
Red: ██████████████
Solid red
The device has detected a un-recoverable
fault
Self test
Red: ▂█▂█▂█▂█▂█▂█▂█
Green: ▂█▂█▂█▂█▂█▂█▂
Flashing red/green
The EIP option is in self-test mode.
NS1 + NS2: Network status (one per port)
State LED Description
No IP-address
(no power)
Off
The device does not have a valid IP-
address (or is un-powered)
No connections
Green: ▂█▂█▂█▂█▂█▂█
Flashing green
There is not established any CIP
connections to the device
Connected
Green: ████████████
Steady green
There is established (at least) one CIP
connection to the device
Connection
time-out
Red: ▂█▂█▂█▂█▂█▂█▂
Flashing red
One or more CIP connections has timed-
out
Duplicate IP
Red: █████████████
Steady red
The IP-address assigned to the device is
already in use
Self test
Red: ▂█▂█▂█▂█▂█▂█▂█
Green: ▂█▂█▂█▂█▂█▂█▂
Flashing red/green
The EIP option is in self-test mode.
During normal operation the both the MS and at least one NS LED will light steady green.

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
