VLT
®
AutomationDrive EtherNet/IP
MG.90.Jx.02 ver. 5
th
September 2007 – VLT is a registered Danfoss trademark 32
Parameters
(8-01) Control Site
Option:
*Digital and control word [0]
Digital only [1]
Control word only [2]
Function:
Select Digital and ctrl. word [0] for control
using both digital input and control word.
Select Digital only [1] for control using digital
inputs only.
Select Control word only [2] for control using
control word only.
The setting in this parameter overrules the
settings in par. 8-50 to 8-56.
(8-02) Control Word Source
Option:
None [0]
FC RS485 [1]
FC USB [2]
*Option A [3]
Option B [4]
Option C0 [5]
Option C1 [6]
Function:
Select the source of the control word: one of
two serial interfaces or four installed options.
This parameter must be set to [3] Option A to
enable control from the EtherNet/IP option.
This parameter cannot be adjusted while the
motor is running.
(8-03) Control Word Timeout Time
Range:
0.1 - 18000.0 s
* 1.0 s
Function:
Enter the maximum time expected to pass
between the reception of two consecutive
telegrams (containing a CTW). If this time is
exceeded, it indicates that the serial
communication has stopped. The function
selected in par. 8-04 Control Word Time-out
Function will then be carried out.
(8-04) Control Word Timeout
Function
Option:
*Off [0]
Freeze Output [1]
Stop [2]
Jogging [3]
Max. Speed [4]
Stop and trip [5]
Select set-up 1 [7]
Select set-up 2 [8]
Select set-up 3 [9]
Select set-up 4 [10]
Function:
Select the time-out function. The time-out
function activates if the following CTW fails to
be updated within the time period specified in
par. 8-03 Control Word Time-out Time.
- Off [0]: Resume control via serial bus
(Fieldbus or standard) using the most recent
control word.
