VLT
®
AutomationDrive EtherNet/IP
- P a r a m e t e r s –
MG.90.Jx.02 ver. 5
th
September 2007 – VLT is a registered Danfoss trademark 33
- Freeze output [1]: Freeze output frequency
until communication resumes.
- Stop [2]: Stop with auto restart when
communication resumes.
- Jogging [3]: Run the motor at JOG frequency
until communication resumes.
- Max. freq.. [4]: Run the motor at maximum
frequency until communication resumes.
- Stop and trip[5]: Stop the motor, then reset
the frequency converter in order to restart: via
the fieldbus, via the reset button on the LCP or
via a digital input.
- Select set-up 1-4 [7] - [10]: This option
changes the set-up upon reestablishment of
communication following a control word time-
out. If communication resumes causing the
time-out situation to disappear, par. 8-05 End-
of-time-out Function defines whether to
resume the set-up used before the time-out or
to retain the set-up endorsed by the time-out
function. Note the following configuration
required in order to change the set-up after a
time-out: Set Par. 0-10 Active set-up to Multi
set-up [9], and select the relevant link in par.
0-12 This Set-up Linked To.
(8-05) End-of-timeout Function
Option:
*Hold set-up [0]
Resume set-up [1]
Function:
Select the action after receiving valid CTW
following a time-out. This parameter is active
only when par. 8-04 is set to Set-up 1-4.
Hold: The frequency converter retains the set-
up selected in par. 8-04 and displays a
warning, until par. 8-06 toggles. Then the
frequency converter resumes its original set-
up.
Resume: The frequency converter resumes the
set-up active prior to the time-out.
(8-06) Reset Control Word Timeout
Option:
*Do not reset [0]
Do reset [1]
Function:
Select Do reset [1] to return the frequency
converter to the original set-up following a
control word time-out. When the value is set to
Do reset [1], the frequency converter performs
the reset and then immediately reverts to the
Do not reset [0] setting.
Select Do not reset [0] to retain the set-up
specified in par. 8-04 Select setup 1-4
following a control word time-out.
This parameter is active only when Hold set-up
[0] has been selected in par. 8-05 End- of-
Time-out Function.
(8-07) Diagnosis Trigger
Option:
*Disable [0]
Trigger on alarms [1]
Trigger on alarms/warn. [2]
Function:
This parameter has no function for EtherNet/IP.
(8-10) Control Word Profile
Option:
*FC profile [0]
ODVA [5]
Function:
Select the interpretation of the control and
status words corresponding to the installed
fieldbus. Only the selections valid for the
fieldbus installed in slot A will be visible in the
LCP display.
(8-13) Configurable Status Word
Option:
No function [0]
* Profile Default [1]
Alarm 68 Only [2]
Trip excl Alarm 68 [3]
T18 DI status [10]
T19 DI status [11]
T27 DI status [12]
T29 DI status [13]
T32 DI status [14]
T33 DI status [15]
T37 DI status [16]
Thermal warning [21]
Brake fault (IGBT) [30]
Out of ref range [40]
Comparator 0 [60]
Comparator 1 [61]
Comparator 2 [62]
Comparator 3 [63]
Comparator 4 [64]
Comparator 5 [65]
Logic Rule 0 [70]
Logic Rule 1 [71]
Logic Rule 2 [72]
Logic Rule 3 [73]
Logic Rule 4 [74]
