Danfoss VLT AutomationDrive Manual

VLT
®
AutomationDrive EtherNet/IP
MG.90.Jx.02 ver. 5
th
September 2007 – VLT is a registered Danfoss trademark 58
Class ID 0x64 – 0xC7 Danfoss Objects
The CIP Class ID 100 to 199 (0x64 to 0xC7) gives access to all drive parameters.
Class (decimal) Danfoss Parameter
range
100 0-01 - 0-99
101 1-00 – 1-99
102 2-00 – 2-99
103 3-00 – 3-99
104 4-00 – 4-99
105 5-00 – 5-99
106 6-00 – 6-99
107 7-00 – 7-99
108 8-00 – 8-99
109 9-00 – 9-99
110 10-00 – 10-99
111 11-00 – 11-99
… …
199 99-00 – 99-99
The class Instance and Attribute acts in the following way:
- 100 added to the parameter group = the value for the class.
- 100 added to the remaining parameter number = the value for the instance.
- 100 added to the array index of the parameter = the value for the attribute.
Examples: (fictitious parameters)
- Parameter 0-01[index 0] = Class 100; Instance 101; Attribute 100
- Parameter 1-00[index 0] = Class 101; Instance 100; Attribute 100
- Parameter 2-59[index 0] = Class 102; Instance 159; Attribute 100
- Parameter 5-34[index 3] = Class 105; Instance 134; Attribute 103
- Parameter 6-54[index 9] = Class 106; Instance 154; Attribute 109
- Parameter 10-01[index 0] = Class 110; Instance 101; Attribute 100
All values in decimal.
All parameters are accessed in the Active setup (par. 0-10 Active Setup)
Implemented Service Name Service Description Service
Code
Class Instance
0Eh Yes Yes Get_Attribute_Single returns contents of specified attribute
10h No Yes Set_Attribute_Single modifies attribute
4Bh No Yes Get_Att_Scattered returns specified parameter values
4Ch No Yes Set_Att_Scattered sets specified parameter values

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
