Danfoss VLT CDS 303 User Manual

13-52 SL Controller Action
Array [20]
Option: Function:
[2] Select set-up
1
Changes the active set-up
(parameter 0-10 Active Set-up) to ‘1’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a eldbus.
[3] Select set-up
2
Changes the active set-up
parameter 0-10 Active Set-up) to ‘2’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a eldbus.
[4] Select set-up
3
Changes the active set-up
(parameter 0-10 Active Set-up) to ‘3’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a eldbus.
[5] Select set-up
4
Changes the active set-up
(parameter 0-10 Active Set-up) to ‘4’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a eldbus.
[10] Select preset
ref 0
Selects preset reference 0.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[11] Select preset
ref 1
Selects preset reference 1.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[12] Select preset
ref 2
Selects preset reference 2.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[13] Select preset
ref 3
Selects preset reference 3.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[14] Select preset
ref 4
Selects preset reference 4.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[15] Select preset
ref 5
Selects preset reference 5.
13-52 SL Controller Action
Array [20]
Option: Function:
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[16] Select preset
ref 6
Selects preset reference 6.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[17] Select preset
ref 7
Selects preset reference 7.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a eldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[20] Select ramp 3 Selects ramp 3.
[21] Select ramp 4 Selects ramp 4.
[22] Run Issues a start command to the frequency
converter.
[23] Run reverse Issues a start reverse command to the
frequency converter.
[24] Stop Issues a stop command to the frequency
converter.
[25] Qstop Issues a quick stop command to the
frequency converter.
[26] Dcstop Issues a DC stop command to the
frequency converter.
[27] Coast The frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
[28] Freeze output Freezes the output frequency of the
frequency converter.
[29] Start timer 0 Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
[30] Start timer 1 Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
[31] Start timer 2 Starts timer 2, see parameter 13-20 SL
Controller Timer for further description.
[32] Set digital out
A low
Any output with SL output A will be low.
[33] Set digital out
B low
Any output with SL output B will be low.
Parameter Descriptions
VLT
®
Compressor Drives CDS 302/CDS 303
100 Danfoss A/S © Rev. 2013-07-03 All rights reserved. MG34M422
6
6
