13-01 Start Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option: Function:
[0] FALSE Select the boolean (TRUE or FALSE)
input to activate Smart Logic Control.
Enters the xed value - FALSE
[1] TRUE Enters the xed value - TRUE.
[2] Running The motor is running.
[3] In range The motor is running within the
programmed current and speed ranges
set in parameter 4-50 Warning Current
Low to parameter 4-53 Warning Speed
High.
[4] On reference The motor is running on reference.
[5] Torque limit The torque limit, set in
parameter 4-16 Torque Limit Motor Mode
or parameter 4-17 Torque Limit Generator
Mode, has been exceeded.
[6] Current Limit The motor current limit, set in
parameter 4-18 Current Limit, has been
exceeded.
[7] Out of current
range
The motor current is outside the range
set in parameter 4-18 Current Limit.
[8] Below I low The motor current is lower than set in
parameter 4-50 Warning Current Low.
[9] Above I high The motor current is higher than set in
parameter 4-51 Warning Current High.
[10] Out of speed
range
The speed is outside the range set in
parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
[11] Below speed
low
The output speed is lower than the
setting in parameter 4-52 Warning Speed
Low.
[12] Above speed
high
The output speed is higher than the
setting in parameter 4-53 Warning Speed
High.
[13] Out of feedb.
range
The feedback is outside the range set in
parameter 4-56 Warning Feedback Low
and parameter 4-57 Warning Feedback
High.
[14] Below feedb.
low
The feedback is below the limit set in
parameter 4-56 Warning Feedback Low.
[15] Above feedb.
high
The feedback is above the limit set in
parameter 4-57 Warning Feedback High.
[16] Thermal
warning
The thermal warning turns on when the
temperature exceeds the limit in the
13-01 Start Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option: Function:
motor, the frequency converter, the
brake resistor or the thermistor.
[17] Mains out of
range
The mains voltage is outside the
specied voltage range.
[18] Reverse The output is high when the frequency
converter is running counter clockwise
(the logical product of the status bits
“running” AND “reverse”).
[19] Warning A warning is active.
[20] Alarm (trip) A (trip) alarm is active.
[21] Alarm (trip lock) A (Trip lock) alarm is active.
[22] Comparator 0 Use the result of comparator 0.
[23] Comparator 1 Use the result of comparator 1.
[24] Comparator 2 Use the result of comparator 2.
[25] Comparator 3 Use the result of comparator 3.
[26] Logic rule 0 Use the result of logic rule 0.
[27] Logic rule 1 Use the result of logic rule 1.
[28] Logic rule 2 Use the result of logic rule 2.
[29] Logic rule 3 Use the result of logic rule 3.
[33] Digital input
DI18
Use the result of digital input 18.
[34] Digital input
DI19
Use the result of digital input 19.
[35] Digital input
DI27
Use the result of digital input 27.
[36] Digital input
DI29
Use the result of digital input 29.
[37] Digital input
DI32
Use the result of digital input 32.
[38] Digital input
DI33
Use the result of digital input 33.
[39] Start command A start command is issued.
[40] Drive stopped A stop command (Jog, Stop, Qstop,
Coast) is issued – and not from the SLC
itself.
[41] Reset Trip A reset is issued
[42] Auto-reset Trip An Auto reset is performed.
[43] OK key [OK] is pressed.
[44] Reset key [Reset] is pressed.
[45] Left key
[◄] is pressed.
[46] Right key
[►] is pressed.
