6.16.10 14-** Special Functions
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
14-0* Inverter Switching
14-00 Switching Pattern [1] SFAVM All set-ups TRUE - Uint8
14-01 Switching Frequency ExpressionLimit All set-ups TRUE - Uint8
14-03 Overmodulation ExpressionLimit All set-ups FALSE - Uint8
14-04 PWM Random [0] O All set-ups TRUE - Uint8
14-1* Mains On/O
14-10 Mains Failure ExpressionLimit All set-ups FALSE - Uint8
14-11 Mains Voltage at Mains Fault ExpressionLimit All set-ups TRUE 0 Uint16
14-12 Function at Mains Imbalance [1] Warning All set-ups TRUE - Uint8
14-13 Mains Failure Step Factor 1 N/A All set-ups TRUE -1 Uint8
14-2* Trip Reset
14-20 Reset Mode [10] Automatic reset x 10 All set-ups TRUE - Uint8
14-21 Automatic Restart Time 30 s All set-ups TRUE 0 Uint16
14-22 Operation Mode [0] Normal operation All set-ups TRUE - Uint8
14-23 Typecode Setting ExpressionLimit 2 set-ups FALSE - Uint8
14-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-26 Trip Delay at Inverter Fault ExpressionLimit All set-ups TRUE 0 Uint8
14-28 Production Settings [0] No action All set-ups TRUE - Uint8
14-29 Service Code 0 N/A All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl.
14-30 Current Lim Cont, Proportional Gain 100 % All set-ups FALSE 0 Uint16
14-31 Current Lim Contr, Integration Time 0.020 s All set-ups FALSE -3 Uint16
14-32 Current Lim Ctrl, Filter Time 26 ms All set-ups TRUE -4 Uint16
14-4* Energy Optimizing
14-40 VT Level 66 % All set-ups FALSE 0 Uint8
14-41 AEO Minimum Magnetisation 40 % All set-ups TRUE 0 Uint8
14-42 Minimum AEO Frequency 30 Hz All set-ups TRUE 0 Uint8
14-43 Motor Cosphi ExpressionLimit All set-ups TRUE -2 Uint16
14-5* Environment
14-50 RFI Filter [1] On 1 set-up FALSE - Uint8
14-52 Fan Control [0] Auto All set-ups TRUE - Uint8
14-53 Fan Monitor [0] Disabled All set-ups TRUE - Uint8
14-55 Output Filter [0] No Filter 1 set-up FALSE - Uint8
14-56 Capacitance Output Filter 2 uF 1 set-up FALSE -7 Uint16
14-57 Inductance Output Filter 7 mH 1 set-up FALSE -6 Uint16
14-6* Auto Derate
14-60 Function at Over Temperature [1] Derate All set-ups TRUE - Uint8
14-61 Function at Inverter Overload [1] Derate All set-ups TRUE - Uint8
14-62 Inv. Overload Derate Current 95 % All set-ups TRUE 0 Uint16
14-9* Fault Settings
14-90 Fault Level ExpressionLimit 1 set-up TRUE - Uint8
Parameter Descriptions
VLT
®
Compressor Drives CDS 302/CDS 303
140 Danfoss A/S © Rev. 2013-07-03 All rights reserved. MG34M422
