Recommended max. fuse
Power[kW]
Bussmann Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
Type JFHR2
1)
JFHR2
JFHR2
2)
J
11 FWX-80 - - HSJ-80
15-18.5 FWX-125 - - HSJ-125
22 FWX-150 L25S-150 A25X-150 HSJ-150
30 FWX-200 L25S-200 A25X-200 HSJ-200
37 FWX-250 L25S-250 A25X-250 HSJ-250
Table 3.12 200-240 V, Frame Sizes B and C
1)
FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
2)
A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency converters.
Recommended max. fuse
Power
[kW]
Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
Type RK1 Type J Type T Type CC Type CC Type CC
11 KTS-R-40 JKS-40 JJS-40 - - -
15 KTS-R-50 JKS-50 JJS-50 - - -
18 KTS-R-60 JKS-60 JJS-60 - - -
22 KTS-R-80 JKS-80 JJS-80 - - -
30 KTS-R-100 JKS-100 JJS-100 - - -
37 KTS-R-125 JKS-125 JJS-125 - - -
45 KTS-R-150 JKS-150 JJS-150 - - -
55 KTS-R-200 JKS-200 JJS-200 - - -
75 KTS-R-250 JKS-250 JJS-250 - - -
Table 3.13 380-500 V, Frame Sizes B and C
Recommended max. fuse
Power
[kW]
SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
Type RK1 Type RK1 Type CC Type RK1
11 5014006-040 KLS-R-40 - A6K-40-R
15 5014006-050 KLS-R-50 - A6K-50-R
18 5014006-063 KLS-R-60 - A6K-60-R
22 2028220-100 KLS-R-80 - A6K-80-R
30 2028220-125 KLS-R-100 - A6K-100-R
37 2028220-125 KLS-R-125 - A6K-125-R
45 2028220-160 KLS-R-150 - A6K-150-R
55 2028220-200 KLS-R-200 - A6K-200-R
75 2028220-250 KLS-R-250 - A6K-250-R
Table 3.14 380-500 V, Frame Sizes B and C
How to Install
VLT
®
Compressor Drives CDS 302/CDS 303
32 Danfoss A/S © Rev. 2013-07-03 All rights reserved. MG34M422
