protect the frequency converter if there is
a fault on the brake modules. Use the
output/relay to cut out the main voltage
from the frequency converter.
[33] Safe Stop
Active
Indicates that the safe stop on terminal 37
is active.
[35] External
Interlock
External Interlock function has been
activated via one of the digital inputs.
[40] Out of ref
range
Active when the actual speed is outside
the settings in parameter 4-52 Warning
Speed Low to parameter 4-55 Warning
Reference High.
[41] Below
reference low
Active when the actual speed is below the
speed reference setting.
[42] Above
reference
high
Active when the actual speed is above the
speed reference setting.
[45] Bus Ctrl Control output via bus. The state of the
output is set in parameter 5-90 Digital &
Relay Bus Control. The output state is
retained in the event of bus time-out.
[46] Bus Ctrl 1 if
timeout
Controls output via bus. The state of the
output is set in parameter 5-90 Digital &
Relay Bus Control. In the event of bus time-
out the output state is set low (On).
[47] Bus Ctrl 0 if
timeout
Controls output via bus. The state of the
output is set in parameter 5-90 Digital &
Relay Bus Control. In the event of bus time-
out the output state is set low (O).
[55] Pulse output
[60] Comparator 0 See parameter group 13-1* Comparators. If
Comparator 0 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[61] Comparator 1 See parameter group 13-1* Comparators. If
Comparator 2 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[62] Comparator 2 See parameter group 13-1* Comparators. If
Comparator 2 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[63] Comparator 3 See parameter group 13-1* Comparators. If
Comparator 3 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[64] Comparator 4 See parameter group 13-1* Comparators. If
Comparator 4 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[65] Comparator 5 See parameter group 13-1* Comparators. If
Comparator 4 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[70] Logic Rule 0 See parameter group 13-4* Logic Rules. If
Logic Rule 0 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[71] Logic Rule 1 See parameter group 13-4* Logic Rules If
Logic Rule 1 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[72] Logic Rule 2 See parameter group 13-4* Logic Rules. If
Logic Rule 2 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[73] Logic Rule 3 See parameter group 13-4* Logic Rules. If
Logic Rule 3 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[74] Logic Rule 4 See parameter group 13-4* Logic Rules. If
Logic Rule 4 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[75] Logic Rule 5 See parameter group 13-4* Logic Rules. If
Logic Rule 5 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[80] SL Digital
Output A
See parameter 13-52 SL Controller Action.
The input will go high whenever the Smart
Logic Action [38] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [32] Set dig. out. A
low is executed.
[81] SL Digital
Output B
See parameter 13-52 SL Controller Action.
The input will go high whenever the Smart
Logic Action [39] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [33] Set dig. out. A
low is executed.
[82] SL Digital
Output C
See parameter 13-52 SL Controller Action.
The input will go high whenever the Smart
Logic Action [40] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [34] Set dig. out. A
low is executed.
[83] SL Digital
Output D
See parameter 13-52 SL Controller Action.
The input will go high whenever the Smart
Logic Action [41] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [35] Set dig. out. A
low is executed.
[84] SL Digital
Output E
See parameter 13-52 SL Controller Action.
The input will go high whenever the Smart
Logic Action [42] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [36] Set dig. out. A
low is executed.
