Danfoss VLT series

F12 IP21/54 – NEMA 1/12 F13 IP21/54 – NEMA 1/12
130BB571.11
2000 (78.74)
607 (23.90)
IP/21 NEMA 1
IP/54
NE
MA
12
2800 m
3
/h
(2472 cfm)
3150 m
3
/h
(
1854 cfm)
4925 m
3
/h
(2900 cfm)
2280 (89.76)
2205 (86.81)
1497 (58.94)
130BB572.11
2800 (110,24)
607 (23.90)
IP/21 NEMA 1
IP/54
NEMA 12
4200 m
3
/h
(2472cfm)
3150
m
3
/h
(1854 cfm)
4925 m
3
/h
(2900 cfm)
2280 (89.76)
2205 (86.81)
1497 (58.94)
All dimensions in mm (in)
Table 3.3 Mechanical Dimensions, Enclosure Sizes F12 and F13
