37.2
(1.47)
36.5
(1.44)
673.0
(26.50)
593.0
(23.35)
37.2
(1.47)
535.0
(21.06)
533.0
(20.98)
603.0
(23.74)
1336.0
(52.60)
258.5
(10.18)
199.5
(7.85)
460.0
(18.11)
130BB698.11
Illustration 3.25 F9, Cable Entry Viewed from the Bottom of the Frequency Converter
70.0
(2.76)
535.0
(21.06)
37.2
(1.47)
36.5
(1.44)
733.0
(28.86)
800.0
(31.50)
1533.0
(60.36)
258.5
(10.18)
199.5
(7.86)
593.0
(23.35)
130BB694.11
Illustration 3.26 F10, Cable Entry Viewed from the Bottom of the Frequency Converter
