34-24 PCD 4 Read from MCO 34-25 PCD 5 Read from MCO 34-26 PCD 6 Read from MCO 34-27 PCD 7 Read from MCO 34-28 PCD 8 Read from MCO 34-29 PCD 9 Read from MCO 34-30 PCD 10 Read from MCO 34-4* Inputs & Outputs 34-40 Digital Inputs 34-41 Digital Outputs 34-5* Process Data 34-50 Actual Position 34-51 Commanded Position 34-52 Actual Master Position
34-53 Slave Index Position
34-54 Master Index Position
34-55 Curve Position 34-56 Track Error 34-57 Synchronizing Error
34-58 Actual Velocity
34-59 Actual Master Velocity
34-60 Synchronizing Status 34-61 Axis Status
34-62 Program Status
34-64 MCO 302 Status
34-65 MCO 302 Control 34-66 SPI Error Counter
34-7* Diagnosis readouts 34-70 MCO Alarm Word 1
34-71 MCO Alarm Word 2
35-** Sensor Input Option 35-0* Temp. Input Mode
35-00 Term. X48/4 Temperature Unit 35-01 Term. X48/4 Input Type
35-02 Term. X48/7 Temperature Unit 35-03 Term. X48/7 Input Type
35-04 Term. X48/10 Temperature Unit
35-05 Term. X48/10 Input Type
35-06 Temperature Sensor Alarm Function
35-1* Temp. Input X48/4 35-14 Term. X48/4 Filter Time Constant
35-15 Term. X48/4 Temp. Monitor
35-16 Term. X48/4 Low Temp. Limit
35-17 Term. X48/4 High Temp. Limit
35-2* Temp. Input X48/7 35-24 Term. X48/7 Filter Time Constant
35-25 Term. X48/7 Temp. Monitor
35-26 Term. X48/7 Low Temp. Limit
35-27 Term. X48/7 High Temp. Limit
35-3* Temp. Input X48/10 35-34 Term. X48/10 Filter Time Constant
35-35 Term. X48/10 Temp. Monitor
35-36 Term. X48/10 Low Temp. Limit
35-37 Term. X48/10 High Temp. Limit
35-4* Analog Input X48/2 35-42 Term. X48/2 Low Current
35-43 Term. X48/2 High Current
35-44 Term. X48/2 Low Ref./Feedb. Value
35-45 Term. X48/2 High Ref./Feedb. Value
35-46 Term. X48/2 Filter Time Constant
36-** Programmable I/O Option 36-0* I/O Mode 36-03 Terminal X49/7 Mode
36-04 Terminal X49/9 Mode
36-05 Terminal X49/11 Mode
36-4* Output X49/7 36-40 Terminal X49/7 Analogue Output
36-42 Terminal X49/7 Min. Scale
36-43 Terminal X49/7 Max. Scale 36-44 Terminal X49/7 Bus Control
36-45 Terminal X49/7 Timeout Preset
36-5* Output X49/9 36-50 Terminal X49/9 Analogue Output
36-52 Terminal X49/9 Min. Scale
36-53 Terminal X49/9 Max. Scale 36-54 Terminal X49/9 Bus Control
36-55 Terminal X49/9 Timeout Preset
36-6* Output X49/11 36-60 Terminal X49/11 Analogue Output
36-62 Terminal X49/11 Min. Scale
36-63 Terminal X49/11 Max. Scale 36-64 Terminal X49/11 Bus Control
36-65 Terminal X49/11 Timeout Preset
42-** Safety Functions 42-1* Speed Monitoring 42-10 Measured Speed Source
42-11 Encoder Resolution 42-12 Encoder Direction
42-13 Gear Ratio 42-14 Feedback Type 42-15 Feedback Filter 42-17 Tolerance Error
42-18 Zero Speed Timer
42-19 Zero Speed Limit
42-2* Safe Input 42-20 Safe Function 42-21 Type 42-22 Discrepancy Time
42-23 Stable Signal Time
42-24 Restart Behaviour
42-3* General 42-30 External Failure Reaction 42-31 Reset Source
42-33 Parameter Set Name
42-35 S-CRC Value 42-36 Level 1 Password
42-4* SS1 42-40 Type 42-41 Ramp Prole 42-42 Delay Time 42-43 Delta T 42-44 Deceleration Rate
42-45 Delta V 42-46 Zero Speed
42-47 Ramp Time 42-48 S-ramp Ratio at Decel. Start 42-49 S-ramp Ratio at Decel. End
42-5* SLS
42-50 Cut O Speed 42-51 Speed Limit 42-52 Fail Safe Reaction
42-53 Start Ramp
42-54 Ramp Down Time
42-6* Safe Fieldbus 42-60 Telegram Selection 42-61 Destination Address 42-8* Status 42-80 Safe Option Status
42-81 Safe Option Status 2
42-82 Safe Control Word
42-83 Safe Status Word
42-85 Active Safe Func.
42-86 Safe Option Info
42-87 Time Until Manual Test
42-88 Supported Customization File Version
42-89 Customization File Version
42-9* Special 42-90 Restart Safe Option 43-** Unit Readouts 43-0* Component Status
43-00 Component Temp.
43-01 Auxiliary Temp.
43-1* Power Card Status 43-10 HS Temp. ph.U
43-11 HS Temp. ph.V 43-12 HS Temp. ph.W 43-13 PC Fan A Speed
43-14 PC Fan B Speed 43-15 PC Fan C Speed 43-2* Fan Pow.Card Status
43-20 FPC Fan A Speed
43-21 FPC Fan B Speed 43-22 FPC Fan C Speed 43-23 FPC Fan D Speed 43-24 FPC Fan E Speed 43-25 FPC Fan F Speed
600-** PROFIsafe 600-22 PROFIdrive/safe Tel. Selected
600-44 Fault Message Counter 600-47 Fault Number
600-52 Fault Situation Counter
601-** PROFIdrive 2 601-22 PROFIdrive Safety Channel Tel. No.
