Danfoss VLT series User Manual

5.6 Electrical Data
Mains supply 6x380–500 V AC
FC 302 P250 P315 P355 P400
High/Normal Load
A)
HO/NO
HO NO HO NO HO NO HO NO
Typical shaft output at 400 V
[kW]
250 315 315 355 355 400 400 450
Typical shaft output at 460 V
[hp]
350 450 450 500 500 600 550 600
Typical shaft output at 500 V
[kW]
315 355 355 400 400 500 500 530
Enclosure protection rating
IP21
F8/F9 F8/F9 F8/F9 F8/F9
Enclosure protection rating
IP54
F8/F9 F8/F9 F8/F9 F8/F9
Output current
Continuous
(at 400 V) [A]
480 600 600 658 658 745 695 800
Intermittent (60 s overload)
(at 400 V) [A]
720 660 900 724 987 820 1043 880
Continuous
(at 460/500 V) [A]
443 540 540 590 590 678 678 730
Intermittent (60 s overload)
(at 460/500 V) [A]
665 594 810 649 885 746 1017 803
Continuous kVA
(at 400 V) [kVA]
333 416 416 456 456 516 482 554
Continuous kVA
(at 460 V) [kVA]
353 430 430 470 470 540 540 582
Continuous kVA
(at 500 V) [kVA]
384 468 468 511 511 587 587 632
Maximum input current
Continuous
(at 400 V) [A]
472 590 590 647 647 733 684 787
Continuous
(at 460/500 V) [A]
436 531 531 580 580 667 667 718
Maximum cable size, mains
[mm
2
(AWG
2)
)]
4x90 (3/0) 4x90 (3/0) 4x240 (500 mcm) 4x240 (500 mcm)
Maximum cable size, motor
[mm
2
(AWG
2)
)]
4x240
(4x500 MCM)
4x240
(4x500 MCM)
4x240
(4x500 MCM)
4x240
(4x500 MCM)
Maximum cable size, brake
[mm
2
(AWG
2)
)
2x185
(2x350 MCM)
2x185
(2x350 MCM)
2x185
(2x350 MCM)
2x185
(2x350 MCM)
Maximum external mains fuses
[A]
1)
700
Estimated power loss
at 400 V [W]
4)
5164 6790 6960 7701 7691 8879 8178 9670
Estimated power loss
at 460 V [W]
4822 6082 6345 6953 6944 8089 8085 8803
Weight,enclosure protection
rating IP21, IP54 [kg (lb)]
440/656 (970/1446)
Eciency
4)
0.98
Output frequency 0–590 Hz
Heat sink overtemperature trip
95 °C (203 °F)
Power card ambient trip
75 °C (167 °F)
A) High overload = 150% torque during 60 s, Normal overload = 110% torque during 60 s
Table 5.1 Mains Supply 6x380–500 V AC
General Specications
VLT
®
AutomationDrive FC 302
76 Danfoss A/S © 04/2016 All rights reserved. MG34Q402
55

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
