Danfoss VLT series User Manual

Mains supply 6x380–500 V AC
FC 302 P450 P500 P560 P630 P710 P800
High/Normal Load
A)
HO/NO
HO NO HO NO HO NO HO NO HO NO HO NO
Typical shaft output at 400 V
[kW]
450 500 500 560 560 630 630 710 710 800 800 1000
Typical shaft output at 460 V [hp] 600 650 650 750 750 900 900 1000 1000 1200 1200 1350
Typical shaft output at 500 V
[kW]
530 560 560 630 630 710 710 800 800 1000 1000 1100
Enclosure protection rating IP21,
54 without/with options cabinet
F10/F11 F10/F11 F10/F11 F10/F11 F12/F13 F12/F13
Output current
Continuous
(at 400 V) [A]
800 880 880 990 990 1120 1120 1260 1260 1460 1460 1720
Intermittent (60 s overload)
(at 400 V) [A]
1200 968 1320 1089 1485 1232 1680 1386 1890 1606 2190 1892
Continuous
(at 460/500 V) [A]
730 780 780 890 890 1050 1050 1160 1160 1380 1380 1530
Intermittent (60 s overload)
(at 460/500 V) [A]
1095 858 1170 979 1335 1155 1575 1276 1740 1518 2070 1683
Continuous kVA
(at 400 V) [kVA]
554 610 610 686 686 776 776 873 873 1012 1012 1192
Continuous kVA
(at 460 V) [kVA]
582 621 621 709 709 837 837 924 924 1100 1100 1219
Continuous kVA
(at 500 V) [kVA]
632 675 675 771 771 909 909 1005 1005 1195 1195 1325
Maximum input current
Continuous
(at 400 V) [A]
779 857 857 964 964 1090 1090 1227 1227 1422 1422 1675
Continuous (at 460/500 V) [A] 711 759 759 867 867 1022 1022 1129 1129 1344 1344 1490
Maximum cable size, motor
[mm
2
(AWG
2)
)]
8x150
(8x300 MCM)
12x150
(12x300 MCM)
Maximum cable size, mains
[mm
2
(AWG
2)
)]
6x120
(6x250 MCM)
Maximum cable size, brake
[mm
2
(AWG
2)
)
4x185
(4x350 MCM)
6x185
(6x350 MCM)
Maximum external mains fuses
[A]
1)
900 1500
Estimated power loss
at 400 V [W]
4)
9492 10647 10631 12338 11263 13201 13172 15436 14967 18084 16392 20358
Estimated power loss
at 460 V [W]
8730 9414 9398 11006 10063 12353 12332 14041 13819 17137 15577 17752
F9/F11/F13 maximum added
losses A1 RFI, CB, or Disconnect,
& contactor F9/F11/F13
893 963 951 1054 978 1093 1092 1230 2067 2280 2236 2541
Maximum panel options losses
[W]
400
Weight,enclosure protection
rating IP21, IP54 [kg (lb)]
1004/1299
(2213/2864)
1004/1299
(2213/2864)
1004/1299
(2213/2864)
1004/1299
(2213/2864)
1246/1541
(2747/3397)
1246/1541
(2747/3397)
Weight Rectier Module [kg (lb)] 102 (225) 102 (225) 102 (225) 102 (225) 136 (300) 136 (300)
Weight Inverter Module [kg (lb)] 102 (225) 102 (225) 102 (225) 136 (300) 102 (225) 102 (225)
Eciency
4)
0.98
Output frequency 0–590 Hz
Heat sink overtemperature trip
95 °C (203 °F)
Power card ambient trip
75 °C (167 °F)
A) High overload = 150% torque during 60 s, Normal overload = 110% torque during 60 s
Table 5.2 Mains Supply 6x380–500 V AC
