Danfoss VLT series User Manual

Mains Supply 6x525–690 V AC
FC 302 P355 P400 P500 P560
High/Normal Load
A)
HO/NO
HO NO HO NO HO NO HO NO
Typical shaft output at 550 V
[kW]
315 355 315 400 400 450 450 500
Typical shaft output at 575 V
[hp]
400 450 400 500 500 600 600 650
Typical shaft output at 690 V
[kW]
355 450 400 500 500 560 560 630
Enclosure protection rating
IP21
F8/F9 F8/F9 F8/F9 F8/F9
Enclosure protection rating
IP54
F8/F9 F8/F9 F8/F9 F8/F9
Output current
Continuous
(at 550 V) [A]
395 470 429 523 523 596 596 630
Intermittent (60 s overload)
(at 550 V) [A]
593 517 644 575 785 656 894 693
Continuous
(at 575/690 V) [A]
380 450 410 500 500 570 570 630
Intermittent (60 s overload)
(at 575/690 V) [A]
570 495 615 550 750 627 855 693
Continuous kVA
(at 550 V) [kVA]
376 448 409 498 498 568 568 600
Continuous kVA
(at 575 V) [kVA]
378 448 408 498 498 568 568 627
Continuous kVA
(at 690 V) [kVA]
454 538 490 598 598 681 681 753
Maximum input current
Continuous
(at 550 V) [A]
381 453 413 504 504 574 574 607
Continuous
(at 575 V) [A]
366 434 395 482 482 549 549 607
Continuous
(at 690 V) [A]
366 434 395 482 482 549 549 607
Maximum cable size, mains
[mm
2
(AWG)]
4x85 (3/0)
Maximum cable size, motor
[mm
2
(AWG)]
4x250 (500 MCM)
Maximum cable size, brake
[mm
2
(AWG)]
2x185
(2x350 MCM)
2x185
(2x350 MCM)
2x185
(2x350 MCM)
2x185
(2x350 MCM)
Maximum external mains fuses
[A]
1)
630
Estimated power loss
at 600 V [W]
4)
5107 6132 5538 6903 7336 8343 8331 9244
Estimated power loss
at 690 V [W]
4)
5383 6449 5818 7249 7671 8727 8715 9673
Weight,
Enclosure protection
rating IP21, IP54 [kg (lb)]
440/656 (970/1446)
Eciency
4)
0.98
Output frequency 0–590 Hz
Heat sink overtemperature trip
85 °C (185 °F)
Power card ambient trip
75 °C (167 °F)
A) High overload = 150% torque during 60 s, Normal overload = 110% torque during 60 s
Table 5.3 Mains Supply 6x525–690 V AC
