Page #83 background image
Mains supply 6x525–690 V AC
FC 302 P1M4 P1M6 P1M8
High/Normal Load
A)
HO/NO
HO NO HO NO HO NO
Typical shaft output at 550 V [kW] 1100 1250 1250 1350 1350 1500
Typical shaft output at 575 V [hp] 1550 1700 1700 1900 1900 2050
Typical shaft output at 690 V [kW] 1400 1600 1600 1800 1800 2000
Enclosure protection rating IP21, IP54
without/with options cabinet
F14/F15
Output current
Continuous
(at 550 V) [A]
1479 1652 1652 1830 1830 2002
Intermittent (60 s overload)
(at 550 V) [A]
2219 1817 2478 2013 2745 2202
Continuous
(at 575/690 V) [A]
1415 1580 1580 1750 1750 1915
Intermittent (60 s overload)
(at 575/690 V) [A]
2122 1738 2370 1925 2625 2107
Continuous kVA
(at 550 V) [kVA]
1409 1574 1574 1743 1743 1907
Continuous kVA
(at 575 V) [kVA]
1409 1574 1574 1743 1743 1907
Continuous kVA
(at 690 V) [kVA]
1691 1888 1888 2091 2091 2289
Maximum input current
Continuous
(at 550 V) [A]
1440 1608 1608 1783 1783 1951
Continuous
(at 575 V) [A]
1378 1538 1538 1705 1705 1866
Continuous
(at 690 V) [A]
1378 1538 1538 1705 1705 1866
Maximum cable size, motor [mm
2
(AWG
2)
)]
12x150
(12x300 MCM)
Maximum cable size, mains F14 [mm
2
(AWG
2)
)]
8x240
(8x500 MCM)
Maximum cable size, mains F15 [mm
2
(AWG
2)
)]
8x400
(8x900 MCM)
Maximum cable size, brake
[mm
2
(AWG
2)
)
6x185
(6x350 MCM)
Maximum external mains fuses [A]
1)
2500
Estimated power loss at 600 V [W]
4)
18843 21464 21464 24147 24147 26830
Estimated power loss at 690 V [W]
4)
19191 21831 21831 24560 24560 27289
F3/F4 Maximum added losses CB or
disconnect & contactor
1016 1267 1277 1570 1570 1880
Maximum panel options losses [W] 400
Weight,enclosure protection rating IP21/
IP54 [kg (lb)]
635/756 (1399/1666) 640/762 (1411/1680) 640/762 (1411/1680)
Weight, rectier module [kg (lb)] 136 (300) 150 (331)
Weight, inverter module [kg (lb)] 136 (300)
Eciency
4)
0.98
Output frequency 0–590 Hz
Heat sink overtemperature trip
85 °C (185 °F)
Power card ambient trip
75 °C (167 °F)
A) High overload = 150% torque during 60 s, Normal overload = 110% torque during 60 s
Table 5.6 Mains Supply 6x525–690 V AC
General Specications Operating Instructions
MG34Q402 Danfoss A/S © 04/2016 All rights reserved. 81
