Danfoss VLT series User Manual

Mains supply 6x525–690 V AC
FC 302 P900 P1M0 P1M2
High/Normal Load
A)
HO/NO
HO NO HO NO HO NO
Typical shaft output at 550 V [kW] 750 850 850 1000 1000 1100
Typical shaft output at 575 V [hp] 1050 1150 1150 1350 1350 1550
Typical shaft output at 690 V [kW] 900 1000 1000 1200 1200 1400
Enclosure protection rating IP21, IP54
without/with options cabinet
F12/F13 F12/F13 F12/F13
Output current
Continuous
(at 550 V) [A]
988 1108 1108 1317 1317 1479
Intermittent (60 s overload)
(at 550 V) [A]
1482 1219 1662 1449 1976 1627
Continuous
(at 575/690 V) [A]
945 1060 1060 1260 1260 1415
Intermittent (60 s overload)
(at 575/690 V) [A]
1418 1166 1590 1386 1890 1557
Continuous kVA
(at 550 V) [kVA]
941 1056 1056 1255 1255 1409
Continuous kVA
(at 575 V) [kVA]
941 1056 1056 1255 1255 1409
Continuous kVA
(at 690 V) [kVA]
1129 1267 1267 1506 1506 1691
Maximum input current
Continuous
(at 550 V) [A]
962 1079 1079 1282 1282 1440
Continuous
(at 575 V) [A]
920 1032 1032 1227 1227 1378
Continuous
(at 690 V) [A]
920 1032 1032 1227 1227 1378
Maximum cable size, motor [mm
2
(AWG
2)
)]
12x150
(12x300 MCM)
Maximum cable size, mains F12 [mm
2
(AWG
2)
)]
8x240
(8x500 MCM)
Maximum cable size, mains F13 [mm
2
(AWG
2)
)]
8x400
(8x900 MCM)
Maximum cable size, brake
[mm
2
(AWG
2)
)
6x185
(6x350 MCM)
Maximum external mains fuses [A]
1)
1600 2000 2500
Estimated power loss at 600 V [W]
4)
13755 15592 15107 18281 18181 20825
Estimated power loss at 690 V [W]
4)
14457 16375 15899 19207 19105 21857
F3/F4 Maximum added losses CB or
disconnect & contactor
556 665 634 863 861 1044
Maximum panel options losses [W] 400
Weight,enclosure protection rating IP21,
IP54 [kg (lb)]
1246/1541 (2747/3397) 1246/1541 (2747/3397) 1280/1575 (2822/3472)
Weight, rectier module [kg (lb)] 136 (300)
Weight, inverter module [kg (lb)] 102 (225) 136 (300)
Eciency
4)
0.98
Output frequency 0–590 Hz
Heat sink overtemperature trip
85 °C (185 °F)
Power card ambient trip
75 °C (167 °F)
A) High overload = 150% torque during 60 s, Normal overload = 110% torque during 60 s
Table 5.5 Mains Supply 6x525–690 V AC
General Specications
VLT
®
AutomationDrive FC 302
80 Danfoss A/S © 04/2016 All rights reserved. MG34Q402
55

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
