Data Aire dap 4 User Manual

57•dap4UserManual
▼PresstheDOWNkeytoviewthenextscreen:
The following will be displayed (values are for reference only):
Note:If(Enable)OFFisselectedtheNormal,Minimum,Maximum,OffsetandValuewillnotbe
displayed.
WithEnableON,Normal,Minimum,Maximum,OffsetandValuewillbedisplayedandvalues
changed.
Once a selection or selections have been made, move the cursor to the title block by pressing the
ENTER key
▼PresstheDOWNkeytoviewthenextscreen:
The following will be displayed (values are for reference only):
Note: If (Enable) OFF is selected the High Res, Offset and Value will not be displayed.
With Enable ON, High Res., Offset and Value will be displayed and values changed.
Once a selection or selections have been made, move the cursor to the title block by pressing the
ENTER key
▼PresstheDOWNkeytoviewthenextscreen:
Analog Input
Static Air Pressure
Enable: Off Channel: B7
Analog Input
Discharge Air Sensor
Enable: On Channel: B9
High Rex. NTC
Offset: 0.0
Value: 74.1
