26 Install the Printer
14. Use the print unit front panel to run the cleaning card.
a. The panel displays the Cleaning message. Press Enter.
b. The Rollers OK? message displays. Press (Return).
c. The Film Checking message displays, followed by Cleaning Start OK?. Press to
start the cleaning process.
The print unit pulls the cleaning card into the print unit. Cleaning displays, and cleaning
begins.
d. The card is discharged in the output area and Cleaning Start OK? displays again.
e. Turn the cleaning card over and place it in the exception card slide with the sticky side
facing down. Refer to step 9 through step 11 to position the cleaning card properly.
f. Press to start the cleaning process.
If the print unit card feed roller is turning but the card is not pulled into the
unit and no errors display, lightly push the card until the roller catches it and
the card moves into the print unit.
