24 Elements of Card Design
Standard Magnetic Stripe Non-Printing Area
The3‐trackmagneticstripetypicallyisonthebackofthecard,whilethesingle‐trackmagnetic
stripeisusuallyonthefrontofthecard.Thegreenarrowshowsthedirectionthecardtravels
throughtheprinter.
Usethefollowingdimensionstopreventprintinginthemagneticstripearea.
Standard Smart Card Non-Printing Area
Thesmartcardareatypicallyisonthefrontofthecard.
Thegreenarrowshowsthedirectionthecardtravels
throughtheprinter.
Usethefollowingdimensionstopreventprintinginthe
smartcardarea.
Custom Non-Printing Areas
UseIDsoftware,acustomapplication,orescapestodefinecustomnon‐printingareasforoneor
moreofthefollowing:
 Blockingprintingbutnottopcoat
 Non‐standardareas,suchasapreprintedlogoorasignatur epanel
 Morethanoneareaonthesamesideofthecard
ABCD
0.88in
22.4mm
1.17in
29.8mm
0.88in
22.4mm
1.47in
37.3mm
ABC
3‐track 3.37in
85.6mm
1.46in
37.1mm
0.66in
16.8mm
2‐track 3.37in
85.6mm
1.57in
39.9mm
0.55in
14mm
Single‐track(JIS) 3.37in
85.6mm
1.60in
40.6mm
0.52in
13.2mm

DataCard SD260 Specifications

General

Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Color	Yes
Print speed (color)	200 card/h
Product color	Blue, Grey

Weight and Dimensions

Depth	391 mm
Width	175 mm
Height	224 mm
