D-500L Firmware V-5.8
K35D03-EN - 77 -
Parameter Definition
Unit
Min
Max
Factory
Set
Description
SMS on Mains Change
-
0
1
0
This parameter controls SMS sending
when mains voltages status is changed.
No warnings generated.
0: no SMS on mains failed or restored
1: SMS sent on mains failed or restored
SMS on IP Change
-
0
1
0
This parameter controls SMS sending
when IP address of GPRS connection is
changed. No warnings generated.
0: no SMS on IP change
1: SMS sent on IP change
E-mail on IP Change
-
0
1
0
This parameter controls e-mail sending
when IP address of GPRS connection is
changed. No warnings generated.
0: no e-mail on IP change
1: e-mail sent on IP change
Fuel Pump Low Limit
%
0
100
20
If the fuel level measured from the
sender input falls below this level, then
the FUEL PUMP function will become
active.
Fuel Pump High Limit
%
0
100
80
If the fuel level measured from the
sender input goes above this level, then
the FUEL PUMP function will become
passive.
Warning Before Start
-
0
1
1
This parameter controls the activation of
the ALARM output during “Engine Start
Delay” timer before engine run.
0: no warning before start
1: warning before start
Latch all Warnings
-
0
1
0
0: warnings are latching/non-latching on
parameter control
1: all warnings are latched. Even if the
fault source is removed, warnings will
persist until manually reset.
Remote Control Enable
-
0
1
1
This parameter controls remote control
of the unit through Rainbow, Modbus
and Modbus TCP/IP.
0: remote control disabled
1: remote control enabled
Annunciator Mode
-
0
1
0
0: normal operation
1: the unit becomes an annunciator of
the remote unit. Engine/genset control
functions are disabled.
CT Location
-
Gen
Load
Gen
0: CTs are at the genset side. Mains
currents are not measured.
1: CTs are at load side. Both mains and
genset currents are monitored following
contactor status.
Reverse CT Direction
-
0
1
0
This parameter is useful to invert all CT
polarities at the same time.
0: normal CT polarity assumed.
1: reverse CT polarity assumed.
16.1. CONTROLLER CONFIGURATION GROUP (continued)
