DKM-411 User Manual Rev_01 Firmware V-1.0
K46D03-EN - 14 -
Supply voltage:
90 to 300V AC
DC supply version: 19-150V DC
Maximum operating
current:
20mA (All options included, digital outputs open.)
Maximum operating power:
< 5VA (All options included, digital outputs open.)
Isolation
3500VAC/1minute from all other terminals.
The connection cables for the power supply voltage
must be fused with a UL listed fuse (6A type C).
3.1. AUXILIARY SUPPLY INPUT
3. TERMINAL DESCRIPTIONS
Power Supply
Connector
