Datakom DKM-411 - Usb Host Port

DKM-411 User Manual Rev_01 Firmware V-1.0
K46D03-EN - 26 -
USB FLASH MEMORY
Description:
USB 2.0, not isolated
Power Supply
Output:
5V, 300mA max
Data rate:
Full Speed 1.5/12 Mbits/s, auto detecting
Connector:
USB-A (PC type connector)
Cable length:
Max 1.5m
Functionality:
USB memory, FAT32, data recording
Memory capacity:
all USB flash memories.
The USB-Host port is designed for detailed data recording. The period of recording is adjustable through
program parameter.
As soon as a USB flash memory is inserted, the unit will start data recording and continue until the
memory is removed.
For more details about data recording please review chapter “Data Recording”.
The USB Flash memory must be formatted for FAT32
file system.
If USB-Device is plugged then USB-Host port will not
function.
3.9. USB HOST PORT
USB HOST
Port
