Datakom DKM-411 - Digital Inputs

DKM-411 User Manual Rev_01 Firmware V-1.0
K46D03-EN - 20 -
Function selection:
from list
Number of inputs:
2 inputs, all configurable
Contact type:
Normally open or normally closed (programmable)
Structure:
Opto-isolated with 10 k-ohms serial resistor.
Isolation voltage:
1000VAC, 1 minute
Measurement:
Digital
Low level threshold:
1.6VDC
High level threshold:
9.0VDC
Maximum input voltage:
±30VDC with respect to input common terminal
Noise filtering:
yes
3.4. DIGITAL INPUTS
Digital Input
Connector
MAX 30V DC or 30V AC
-
+
