DKM-411 User Manual Rev_01 Firmware V-1.0
K46D03-EN - 86 -
The unit offers the possibility of SNMP communication through its Ethernet port (10/100Mb)
Below parameters may be set to the controller:
Control Buttons
Below parameters may be read from the controller:
Voltages (L1, L2, L3, L12, L23, L31)
Currents (I1, I2, I3, IN)
Active Power (L1, L2, L3, Total)
Reactive Power (L1, L2, L3, Total)
Apparent Power (L1, L2, L3, Total)
Power Factor (L1, L2, L3, Total)
Frequency
Total kW-h counter-1
Total kVAR-h inductive counter-1
Total kVAR-h capacitive counter-1
Incremental Counter-1
Total kW-h counter-2
Total kVAR-h inductive counter-2
Total kVAR-h capacitive counter-2
Incremental Counter-2
Alarm List
Warning List
Modbus Slave Address: may be set between 1 and 240. If only one unit is available in the same IP
address, it is advised to keep the default address (1).
Ethernet Enable: This parameter should be set to 1 (or checked) in order to enable the ethernet port.
Modbus TCP/IP Port: The usual setting is 502. However the unit is able to work on any port address.
User IP Mask: There are 3 mask registers available. The use of the registers are emphasized in the
DKM-411 User Manual. Please set the first mask as 255.255.255.0 for the proper operation.
Ethernet Network IP: May be left as 0.0.0.0 for automatic address claim or set to a value in order to
claim a defined address.
Ethernet Gateway IP: Should be set in accordance with your local switch configuration.
Ethernet Subnet Mask: Should be set in accordance with your local switch configuration.
The complete Ethernet port specifications are found in the DKM-411 User Manual.
Please rewiev the document Ethernet Configuration Guide for DKM-411 for more details about the
ethernet port setup.
