DKM-411 User Manual Rev_01 Firmware V-1.0
K46D03-EN - 85 -
Below is a shortlist of available Modbus registers. For complete register map please refer to DKM-411
Modbus Application Manual.
ADDRESS
(decimal)
R / W
DATA
SIZE
COEFF.
DESCRIPTION
20480
R
32bit
x10
Phase L1 voltage
20482
R
32bit
x10
Phase L2 voltage
20484
R
32bit
x10
Phase L3voltage
20486
R
32bit
x10
Phase L1-L2 voltage
20488
R
32bit
x10
Phase L2-L3 voltage
20490
R
32bit
x10
Phase L3-L1voltage
20492
R
32bit
x10
Phase L1 current
20494
R
32bit
x10
Phase L2 current
20496
R
32bit
x10
Phase L3 current
20498
R
32bit
x10
Neutral current
20500
R
32bit
x10
Phase L1 active power
20502
R
32bit
x10
Phase L2active power
20504
R
32bit
x10
Phase L3active power
20506
R
32bit
x10
Total active power
20508
R
32bit
x10
Phase L1 reactive power
20510
R
32bit
x10
Phase L2reactive power
20512
R
32bit
x10
Phase L3reactive power
20514
R
32bit
x10
Total reactive power
20516
R
32bit
x10
Phase L1 apparent power
20518
R
32bit
x10
Phase L2apparent power
20520
R
32bit
x10
Phase L3apparent power
20522
R
32bit
x10
Total apparent power
20524
R
16bit
x10
Phase L1 power factor
20525
R
16bit
x10
Phase L2power factor
20526
R
16bit
x10
Phase L3power factor
20527
R
16bit
x10
Total power factor
20528
R
16bit
x100
Frequency
20529
-
-
-
-
20530
-
-
-
-
20531
-
-
-
-
20532
R
32bit
X10
Average Ph-N voltage
20534
R
32bit
X10
Average Ph-Ph voltage
20536
R
32bit
X10
Average current
20538
R
16bit
x10
Phase L1 tangent(teta) P1/Q1
20539
R
16bit
x10
Phase L2 tangent(teta) P2/Q2
20540
R
16bit
x10
Phase L3 tangent(teta) P3/Q3
20541
R
16bit
x10
Total tangent(teta) P/Q
20542
R
16bit
x10
Voltage Unbalance %
20543
R
16bit
x10
Current Unbalance %
