DKM-411 User Manual Rev_01 Firmware V-1.0
K46D03-EN - 21 -
Structure:
Isolated relay output, normally open contact. One terminal is
internally connected to relay common terminal
Number of outputs:
2 outputs, both configurable
Function selection:
from list
Max switching current:
5A @250VAC/30VDC
Max switching voltage:
250VAC
Max switching power:
1250VA
Isolation:
2000VAC from all other terminals.
INTERNAL STRUCTURE OF RELAY OUTPUTS:
MAX 5A
30V DC or
250V AC
RL1A
RL2A
RLCOM
3.5. DIGITAL OUTPUTS
Digital Output
Connector
