The unit provides a set of incremental counters for statistical purposes. These counters are stored in a
non-volatile memory and retain their values even when power is off.
The unit offers two sets of counters. This is in order to enable the user totalize separately genset and
mains counters. Counter sets can be switched with external signal, enabling sophisticated applications.
Incremental counters will count with external signal coming from digital inputs. Therefore external events
may be counted and transmitted through internet.
The counters consist on:
-total imported kWh-1
-total exported kWh-1
-total kVArh inductive-1
-total kVArh capacitive-1
-incremental counter-1
-total imported kWh-2
-total exported kWh-2
-total kVArh inductive-2
-total kVArh capacitive-2
-incremental counter-2
