Datalogic Gryphon I GBT4400 2D User Manual

LED and Beeper Indications
44 Gryphon™ I GBT4400 2D
Programming Mode - The following indications ONLY occur when the
reader is in Programming Mode.
INDICATION DESCRIPTION LED BEEPER
Label Programming
Mode Entry
A valid programming
label has been
scanned.
LED blinks
continu-
ously
Reader sounds
four low fre-
quency beeps.
Label Programming
Mode Rejection of
Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest frequency
and current vol-
ume.
Label Programming
Mode Acceptance of
Partial Label
In cases where multi-
ple labels must be
scanned to program
one feature, this indi-
cation acknowledges
each portion as it is
successfully scanned.
N/A
Reader sounds
one short beep at
highest frequency
and current vol-
ume.
Label Programming
Mode Acceptance of
Programming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Programming
Mode.
N/A
Reader sounds
one high fre-
quency beep and
4 low frequency
beeps followed by
reset beeps.
Label Programming
Mode Cancel Item
Entry
Cancel label has been
scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.

Datalogic Gryphon I GBT4400 2D Specifications

General

Scanner Type	2D Imager
Connectivity	Bluetooth
IP Rating	IP52
Print Contrast Ratio (Minimum)	25%
Interface	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Drop Resistance	1.8 m (6 ft) to concrete
Weight	245 g / 8.64 oz
Dimensions	18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in
Light Source	Red LED
Image Sensor	CMOS
Decode Capability	1D / 2D / Postal / Stacked codes
Scanning Technology	Imaging
Resolution	752 x 480 pixels
Skew Angle	+/- 65°
Humidity	5 to 95% non-condensing
Drop Specification	1.8 m (6 ft) to concrete
Power Supply	5 VDC +/- 5%
Beeper	Yes
Indicators	LEDs, Beeper
Supported Barcodes	All standard 1D and 2D barcodes
