Enter/Exit Programming Mode1D Code Selection
192
Gryphon™ I GD44XX/GBT4400/GM440X
Code 11 Set Length 1
This feature specifies one of the bar code lengths for Code 11 Length Con-
trol. Length 1 is the minimum label length if in Variable Length Mode, or the
first fixed length if in Fixed Length Mode. Length includes
the bar code’s
check and data characters. The length can be
set from 2 to 50 characters.
Table 15 provides some examples for setting Length 1. See page 283 for
detailed instructions on setting this feature.
Table 15. Code 11 Length 1 Setting Examples
STEP ACTION EXAMPLES
1
Desired Setting (pad with
leading zeroes)
02 Characters 07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 11 LENGTH 1 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘2 ‘0’ and ‘7 ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CC1L1
Select Code 11 Set Length 1 Setting
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start again
at the beginning.
~
CANCEL
DEFAULT
04 = Length 1 is 4 Characters
