Datalogic Gryphon I GD4400 User Manual

Enter/Exit Programming Mode
254 Gryphon™ I GD44XX/GBT4400/GM440X
BATCH FEATURES
Batch Mode
This option specifies whether to store labels in the handheld while discon-
nected from the base. Options are as follows:
• Disabled — The handheld will not store/batch labels.
• Automatic — The handheld will store labels to RAM when the handheld
go
es out of range and is disconnected from the remote device.
• Manual — The handheld will always store labels to Flash memory. The
u
ser must manually send the stored labels to the remote device using a
special "batch send" label.
DEFAULT
$CBTBM00(CR)
Batch Mode = Disabled
$CBTBM01(CR)
Batch Mode = Automatic
$CBTBM02(CR)
Batch Mode = Manual
Send Batch
When the scanner is configured in Manual Batch Mode, use the following bar
code to initiate sending of labels stored in batch memory.
BatchSend
Send Batch
Do not scan an ENTER/EXIT PROGRAMMING MODE label in conjunc-
tion with this bar code.

Datalogic Gryphon I GD4400 Specifications

General

Environmental Sealing	IP52
Dimensions	18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in
Connectivity Technology	Wired
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Ambient Light Immunity	0 to 100, 000 lux
ESD Protection	16 kV
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Resolution	4 mils
Drop Resistance	Withstands drops from 1.8 m / 5.9 ft to concrete
Weight	195 g / 6.88 oz
Decode Capability	1D Codes, 2D Codes, Postal Codes, Stacked Codes
Scan Rate	Up to 60 frames per second
