MATRIX 400™ CODE QUALITY VERIFIER SOLUTION
4
5.3 STARTUP
After completing the mechanical and electrical connections to Matrix 400™, you can begin
software configuration as follows:
1. Power on the Matrix 400™ reader. Wait for the reader startup. The system bootstrap
requires a few seconds to be completed. The reader automatically enters Run Mode.
2. Run the VisiSet™ program.
3. Press Connect on the VisiSet™ menu bar. The PC will automatically connect to the
Matrix 400™ reader.
Upon connection, Matrix 400™ exits Run Mode and displays the Main Menu on VisiSet™
with all the commands necessary to monitor your reader's performance. You can select
these commands using the mouse or by pressing the key corresponding to the letter shown
on the button. See Figure 23.
Terminal
Window
Menu Bar
Commands
Window
Status Bar
Figure 23 – VisiSet™ Main Window
52
