SOFTWARE CONFIGURATION
46
5.4.5 Digital Outputs Activation
Matrix 400™ digital outputs can be used to indicate if one or more grades of the decoded
symbol fall become lower than the selected threshold grade.
DIGITAL I/O - OUTPUT 1,2
Activation Events
Defines the event(s) which will activate the output. Among the available activating event
selections, several Standard Code Quality Parameters are listed. If selected, the codes read
must meet or exceed these Standards in order to avoid output activation.
It is possible to select more than one event so that any one of them will cause the output
activation. To do this, from the pull down menu, hold down the CTRL key and select the
desired events with the mouse. The events will be listed separated by a comma.
By selecting None the output is always in idle state.
ISO-IEC 16022-18004 Threshold
This parameter is available when the ISO-IEC 16022-18004 Status parameter is enabled.
It defines the grade threshold for the
ISO/IEC 16022 and ISO/IEC 18004 code quality
parameter(s) selected in Activation Events, under which the output will be activated. A code
presented to the reader which has at least one of the selected code quality parameter grades
lower than that specified in this parameter will activate the output.
The valid Activation Events for this standard are:
• ISO-IEC Symbol Contrast
• ISO-IEC Print Growth
• ISO-IEC / AIM DPM Axial Non Uniformity
• ISO-IEC / AIM DPM Unused Error Correction
ISO-IEC 15415 Threshold
This parameter is available when the ISO-IEC 15415 Status parameter is enabled.
It defines the grade threshold for the
ISO/IEC 15415 code quality parameter(s) selected in
Activation Events, under which the output will be activated. A code presented to the reader
which has at least one of the selected code quality parameter grades lower than that
specified in this parameter will activate the output.
The valid Activation Events for this standard are:
• ISO-IEC Symbol Contrast
• ISO-IEC / AIM DPM Axial Non Uniformity
• ISO-IEC / AIM DPM Unused Error Correction
• ISO-IEC Modulation
• ISO-IEC / AIM DPM Fixed Pattern Damage
• ISO-IEC / AIM DPM Grid Non Uniformity
• ISO-IEC / AIM DPM Decode
ISO-IEC 15416 Threshold
This parameter is available when the ISO-IEC 15416 Status parameter is enabled.
It defines the grade threshold for the
ISO/IEC 15416 code quality parameter(s) selected in
Activation Events, under which the output will be activated.
A code presented to the reader which has at least one of the selected code quality parameter
grades lower than that specified in this parameter will activate the output.
