MATRIX 400™ CODE QUALITY VERIFIER SOLUTION
6
6 TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
Supply Voltage 10 to 30 Vdc
Power Consumption 0.8 to 0.27 A, 8 W max.; 0.5 to 0.17 A, 5 W typical
Communication Interfaces
Main
- RS232
- RS485 full-duplex
- RS485 half-duplex
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
Auxiliary - RS232 2400 to 115200 bit/s
ID-NET™ Up to 1MBaud
Ethernet (Ethernet Models only) 10/100 Mbit/s
Inputs
Input 1 (External Trigger) and Input 2
Opto-coupled and polarity insensitive
Outputs
Output 1 and Output 2
Opto-coupled
OPTICAL FEATURES 400 4xx-xxx models 400 6xx-xxx models
Image Sensor CMOS CCD
Image Format SXGA (1280x1024) UXGA (1600x1200)
Frame Rate 27 frames/sec. 15 frames/sec.
Pitch
± 35°
Tilt 0° - 360°
Lighting System Internal or External Illuminator (accessories)
LED Safety Class Class 1 to EN60825-1
ENVIRONMENTAL FEATURES
Operating Temperature
0 to 50 °C (32 to 122 °F)
(high ambient temperature applications should use metal mounting
bracket for heat dissipation)
Storage Temperature
-20 to 70 °C (-4 to 158 °F)
Max. Humidity 90% non condensing
Protection Class IP67 *
PHYSICAL FEATURES
Dimensions 123 x 60.5 x 87 mm (4.85 x 2.38 x 3.43 in.) with lens cover
Weight 482 g. (17 oz.) with lens and internal illuminator
Material Aluminium
72
