SOFTWARE CONFIGURATION
46
5.4.6 Code Filtering
Matrix 400™ digital outputs allows ordering read codes and filtering them according to their
symbology, length, position and quality grades.
DATA COLLECTION - CODE FILTER SETTING
Code Quality Index
The Code Quality Index allows selecting from a list of Standard code quality parameters,
which the codes read must meet or exceed in order to be accepted in the collection.
ISO-IEC 16022-18004 Threshold
This parameter is available when the ISO-IEC 16022-18004 Status parameter is enabled.
It defines the grade threshold for the ISO/IEC 16022 and ISO/IEC 18004 code quality
parameter selected in Code Quality Index, under which the code will be filtered. A code
presented to the reader which has a code quality parameter grade lower than that specified
in this parameter will cause the code to be filtered (not collected).
The valid code quality parameters for this standard are:
• ISO-IEC / AIM DPM Overall Grade
• ISO-IEC Symbol Contrast
• ISO-IEC Print Growth
• ISO-IEC / AIM DPM Axial Non Uniformity
• ISO-IEC / AIM DPM Unused Error Correction
ISO-IEC 15415 Threshold
This parameter is available when the ISO-IEC 15415 SYMBOL VERIFICATION parameter is
enabled. It defines the grade threshold for the ISO/IEC 15415 code quality parameter
selected in Code Quality Index, under which the code will be filtered. A code presented to the
reader which has a code quality parameter grade lower than that specified in this parameter
will cause the code to be filtered (not collected).
The valid code quality parameters for this standard are:
• ISO-IEC / AIM DPM Overall Grade
• ISO-IEC Symbol Contrast
• ISO-IEC / AIM DPM Axial Non Uniformity
• ISO-IEC / AIM DPM Unused Error Correction
• ISO-IEC Modulation
• ISO-IEC / AIM DPM Fixed Pattern Damage
• ISO-IEC / AIM DPM Grid Non Uniformity
• ISO-IEC / AIM DPM Decode
ISO-IEC 15416 Threshold
This parameter is available when the ISO-IEC 15416 Status parameter is enabled.
It defines the grade threshold for the ISO/IEC 15416 code quality parameter selected in
Code Quality Index, under which the code will be filtered. A code presented to the reader
which has a code quality parameter grade lower than that specified in this parameter will
cause the code to be filtered (not collected).
The valid code quality indexes for this standard are:
• ISO-IEC / AIM DPM Overall Grade
• ISO-IEC Symbol Contrast
