MATRIX 400™ CODE QUALITY VERIFIER SOLUTION
4
The valid Activation Events for this standard are:
• ISO-IEC Symbol Contrast
• ISO-IEC Modulation
• ISO-IEC Min Edge Contrast
• ISO-IEC Decodability
• ISO-IEC / AIM DPM Minimum Reflectance
• ISO-IEC Defects
• ISO-IEC / AIM DPM Decode
AIM DPM Threshold
This parameter is available when the AIM DPM Status parameter is enabled.
It defines the grade threshold for the AIM DPM code quality parameter(s) selected in
Activation Events, under which the output will be activated. A code presented to the reader
which has at least one of the selected code quality parameter grades lower than that
specified in this parameter will activate the output.
The valid Activation Events for this standard are:
• ISO-IEC / AIM DPM Axial Non Uniformity
• ISO-IEC / AIM DPM Unused ECC
• ISO-IEC / AIM DPM Fixed Pattern Damage
• ISO-IEC / AIM DPM Grid Non Uniformity
• ISO-IEC / AIM DPM Minimum Reflectance
• ISO-IEC / AIM DPM Decode
• AIM DPM Cell Contrast
• AIM DPM Cell Modulation
AS9132 (Parameter not visible)
AS9132 parameters are calculated on Pass/Fail basis: when the AS9132A Status parameter
is enabled, a code presented to the reader which has at least one of the selected code
quality parameter grades equal to Fail will activate the output.
The valid Activation Events for this standard are:
• AS9132 Dot Size/Cell Fill
• AS9132 Dot Center Offset
• AS9132 Dot Ovality
• AS9132 Quiet Zone
• AS9132 Angle Of Distortion
• AS9132 Symbol Contrast
Number of Events
Defines the number of activation events which must occur within the last #N reading phases
to activate the output.
Number of Reading Phases
Defines the number of reading phases during which the selected Activation Events are
examined.
64
