Parameters to verify/modify:
Operating Mode Sets the parameters which customize the reader operating
mode starting from three main modes:
One Shot: acquires a single image based on the selected
value for the Acquisition Trigger and Acquisition Trigger
Delay.
Continuous: continuously acquires images with a rate up to
the maximum allowable frame rate per second for the
given sensor depending on the decoding time and the
Region of Interest settings.
Phase Mode: acquires images during the reading phase
depending on the selected value for the Acquisition Trigger
and Acquisition Trigger Delay. The Reading Phase ON
and Reading Phase OFF events mark respectively the
beginning and end of the reading phase.
Calibration Calibrates the acquisition parameters to maximize the
reading performance.
Communication Configures the parameters relative to each serial port
regarding the transmission, message formatting and string
receiving.
Any change to the VisiSet™ communication port
parameters (baud rate, data bits, etc.) is effective as soon
as the reader is disconnected from VisiSet™.
Ethernet Sets the parameters related to the Ethernet interface and
to its communication channels.
Reading System Layout Allows configuring the device according to the desired
layout: Standalone, ID-NET™ or Master/Slave RS232
Image Processing Sets the image processing parameters shared by all
available symbologies.
1D & 2D, Postal Codes
Sets the characteristics of the code symbologies to be
read.
Data Collection Defines the code-collection parameters and the output
message format.
Digital I/O Configures the reader input/output parameters.
Match Code Allows setting a user-defined code and relative parameters
to which the read code will be compared (matched).
Miscellaneous Sets the reader name and the saved image format.
Symbol Verification Sets the parameters relative to the various specifications in
the Standards which regulate code validation.
LEDs And Keypad Sets the X-PRESS™ LED and Keypad parameters related to
their selected Functions: Beeper, Green Spot, Autolearning,
Positioning, etc.
