Datalogic Memor User Manual

1 DATALOGIC MEMOR™
4
1
1.3 PACKAGE CONTENTS
The Datalogic Memor package contains:
− 1 Datalogic Memor mobile computer
− 1 AC/DC power supply
− 1 EU plug adapter
− 1 UK Plug Adapter
− 1 standard Mini USB cable
− 1 extensible stylus
− 1 rechargeable standard battery pack + cover
− 1 hand-strap with stylus holder
− 1 Quick Start Guide
− 1 Safety and Regulatory Addendum
− 1 Wavelink Avalanche Insert
− 1 End User License Agreement (EULA) Sheet
Any other packages will contain the accessories necessary for the Datalogic Memor
connection to the host computer and to the network: the cradle, one or more
connection cables.
Remove all the components from their packaging; check their integrity and compare
them with the packing documents.
Keep the original packaging for use when sending products to the
technical assistance center. Damage caused by improper
packaging is not covered under the warranty.
CAUTION
Rechargeable battery packs are not initially fully charged. Therefore
the first operation to perform is to charge them. See section 2.1.
NOTE

Datalogic Memor Specifications

General

Scan speed	104 sec/page
Wavelength	630 nm
Sensor type	Laser
Decoding standards	UPC A, UPC E, EAN 8, EAN 13, Code 39, Code 39 Full ASCII, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 128, EAN 128, Codabar, MSI, Plessey, Code 93, Code 11, GS1 Databar.
Product color	Black
Internal memory	256 MB
Built-in processor	PXA310
Display resolution	240 x 320 pixels
Processor frequency	624 MHz
Bluetooth	Yes
Standard interfaces	USB, RS-232
Battery type	Li-polymer/Li-ion
Input voltage	5 V
Power consumption	1100 mA
Safety	Class 2
Display	Reflective TFT 64K
Dimensions (WxDxH)	152 x 55 x 40 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Weight	230 g
