Datalogic Memor User Manual

1 DATALOGIC MEMOR™
8
1
1.5 ACCESSORIES
 Cradles
94A151111 DL-Memor Single Cradle w Aux. Slot
94A151121 Dock Memor Vehicle w Power Adapter
94A151122 DL-Memor Single Ethernet-Usb_Host Cradle
94A151123 DL-Memor Multi Battery Charger
 Batteries
94ACC1367 DL-Memor Large Capacity Battery CVR2
94ACC1368 DL-Memor Standard Battery CVR2
 Power Supply
94ACC1324 PG5-30P35 AC/DC Power Supply EU/USA Plug
94ACC1334 PG5-30P35 AUS. Plug Adapter (10pcs)
94ACC1335 PG5-30P35 UK Plug Adapter (10pcs)
94ACC1339 PG5-30P35 EU. Plug Adapter (10pcs)
94ACC1369 DL-Memor Alkaline Adapter CVR2
 Cables
94A051016 CAB-421 USB Type A-B-Mini Straight
94A051022 WIN-NET Serial CAB (HRS ST40x-18S-CV)
94A051024 USB A (4 pin F) to Mini A (5 pin M)
94A051966 Cable Memor 12 TO 24 V Power Adapter
 Various
94ACC1328 DL-Memor Stylus Pen (10pcs)
94ACC1365 Headset Memor
94ACC1366 Softcase Memor w/Swivel
Use only a Datalogic approved power supply and cables. Use of an
alternative power supply will invalidate any approval given to this
device and may be dangerous.
NOTE

Datalogic Memor Specifications

General

Scan speed	104 sec/page
Wavelength	630 nm
Sensor type	Laser
Decoding standards	UPC A, UPC E, EAN 8, EAN 13, Code 39, Code 39 Full ASCII, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 128, EAN 128, Codabar, MSI, Plessey, Code 93, Code 11, GS1 Databar.
Product color	Black
Internal memory	256 MB
Built-in processor	PXA310
Display resolution	240 x 320 pixels
Processor frequency	624 MHz
Bluetooth	Yes
Standard interfaces	USB, RS-232
Battery type	Li-polymer/Li-ion
Input voltage	5 V
Power consumption	1100 mA
Safety	Class 2
Display	Reflective TFT 64K
Dimensions (WxDxH)	152 x 55 x 40 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Weight	230 g
