Datalogic Memor User Manual

TECHNICAL FEATURES
95
5
5 TECHNICAL FEATURES
5.1 TECHNICAL DATA
PHYSICAL CHARACTERISTICS
DIMENSIONS (LxWxH) 15.2 x 5.5 x 4.0 cm / 5.9 x 2.2 x 1.6 in
WEIGHT
(DEPENDING ON MODEL)
220 g / 7.76 oz (incl. 1100 mAH battery)
250 g / 8.81 oz (incl. 2000 mAH battery)
AUDIO
Rear Speaker for beeps and ringing tones
Microphone and Front Speaker for phone calls
Headset
LEDS
Two-color Good Read/Programmable
Charging Status
DISPLAY
64K Color TFT LCD with 320 x 240 pixel resolution
(QVGA), with LED backlight
and touch screen,
antiglare and antiscratch protection
KEYBOARD
23 Plastic Top - Backlit Keys + Joystick +
lateral ON/OFF key
OPERATING
TEMPERATURE*
0° to +50 °C / 32 °F to +122 °F
STORAGE TEMPERATURE -20° to +70 °C / -4° to +158 °F
HUMIDITY** 10 to 80% non condensing for temperatures < 38 °C
DROP RESISTANCE*** 1.2 M / 3.9 FT
ENVIROMENTAL SEALING IP54
ESD PROTECTION 4 KV contact discharge, 8 KV air discharge
* Battery should be charged at an ambient temperature between 0 - 40º C to achieve the
maximum charging rate. Never charge the main device or spare batteries in a closed space
where excessive heat can build up.
Close to the limits of the working temperature, some display and/or battery performance
degradation may occur.
** Multiple rapid humidity and/or temperature variations may cause condensing.
*** Multiple drops can permanently damage the device.

Datalogic Memor Specifications

General

Scan speed	104 sec/page
Wavelength	630 nm
Sensor type	Laser
Decoding standards	UPC A, UPC E, EAN 8, EAN 13, Code 39, Code 39 Full ASCII, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 128, EAN 128, Codabar, MSI, Plessey, Code 93, Code 11, GS1 Databar.
Product color	Black
Internal memory	256 MB
Built-in processor	PXA310
Display resolution	240 x 320 pixels
Processor frequency	624 MHz
Bluetooth	Yes
Standard interfaces	USB, RS-232
Battery type	Li-polymer/Li-ion
Input voltage	5 V
Power consumption	1100 mA
Safety	Class 2
Display	Reflective TFT 64K
Dimensions (WxDxH)	152 x 55 x 40 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Weight	230 g
