Datalogic Memor User Manual

1 DATALOGIC MEMOR™
84
4
4.10.2 Setting Hot Keys
You can use Hot Keys (HKeys) Tab to associate specific keys, such as <F1>-<F10>,
with specific applications. You can also create a new Hot Key combinations. Select
the HKeys tab to access these options.
For example, you could set <F2> to launch a sample application like:
\Windows\pword.exe.
COMMAND DESCRIPTION
Hot Key
This pull-down list displays the available function keys
to define. Select the desired one from the list.
New
Select/tap to specify a new Hot Key, not on the Hot Key
list. This opens a new dialog, shown in Figure 4.
Delete
Tap to delete the selected Hot Key. You can only delete
the Hot Keys you have added. You cannot delete
<F1>
-<F10>.
Associated Function
This pull-down list displays the available functions.
Select either Application or Action.
Application
Displays path to the selected application.

Datalogic Memor Specifications

General

Scan speed	104 sec/page
Wavelength	630 nm
Sensor type	Laser
Decoding standards	UPC A, UPC E, EAN 8, EAN 13, Code 39, Code 39 Full ASCII, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 128, EAN 128, Codabar, MSI, Plessey, Code 93, Code 11, GS1 Databar.
Product color	Black
Internal memory	256 MB
Built-in processor	PXA310
Display resolution	240 x 320 pixels
Processor frequency	624 MHz
Bluetooth	Yes
Standard interfaces	USB, RS-232
Battery type	Li-polymer/Li-ion
Input voltage	5 V
Power consumption	1100 mA
Safety	Class 2
Display	Reflective TFT 64K
Dimensions (WxDxH)	152 x 55 x 40 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Weight	230 g
